The Entanglement Advantage

Sensing networks achieve greater precision through quantum entanglement

Entanglement enlarge

Entanglement, a special property of nature at the quantum level, is a correlation between two or more objects. A research team recently harnessed entanglement to develop more precise networked quantum sensors. (Image by Brookhaven National Laboratory.)

Researchers affiliated with the Q-NEXT quantum research center show how to create quantum-entangled networks of atomic clocks and accelerometers — and they demonstrate the setup’s superior, high-precision performance.

What happened

For the first time, scientists have entangled atoms for use as networked quantum sensors, specifically, atomic clocks and accelerometers.

The research team’s experimental setup yielded ultraprecise measurements of time and acceleration. Compared to a similar setup that does not draw on quantum entanglement, their time measurements were 3.5 times more precise, and acceleration measurements exhibited 1.2 times greater precision.

The result, published in Nature, is partially supported by Q-NEXT, a U.S. Department of Energy (DOE) National Quantum Information Science Research Center led by DOE’s Argonne National Laboratory. The research was conducted by scientists at Stanford University, Cornell University and DOE’s Brookhaven National Laboratory.

“The impact of using entanglement in this configuration was that it produced better sensor network performance than would have been available if quantum entanglement were not used as a resource,” said Mark Kasevich, lead author of the paper, a member of Q-NEXT, the William R. Kenan, Jr. professor in the Stanford School of Humanities and Sciences and professor of physics and of applied physics. “For atomic clocks and accelerometers, ours is a pioneering demonstration.”

What is quantum entanglement? How does it apply to sensors?

  • Entanglement, a special property of nature at the quantum level, is a correlation between two or more objects. When two atoms are entangled, one can measure the properties of both atoms by observing only one. This is true no matter how much distance — even if it’s light-years — separates the entangled atoms.
  • A helpful everyday analogy: A red marble and a blue marble are placed in a box. If you draw a red marble from the box, you know, without having to look at the other one, that it’s blue. The color of the marbles is correlated, or entangled.
  • In the quantum realm, entanglement is subtler. An atom can take on multiple states (colors) at once. If our marbles were like atoms, each marble would be both red and blue at the same time. Neither is fully red or blue while it sits the box. The quantum marble “decides” its color only at the moment of revelation. And once you draw one marble of “decided” color, you know the color of its entangled partner.
  • To take a measurement of one member of an entangled pair is effectively to take a simultaneous reading of both.
  • Taking this further: Two entangled clocks are practically equivalent to a single clock with two displays. Time measurements taken using entangled clocks can be more precise than measurements from two separate, synchronized clocks.

Why it matters

Greater sensitivity in atomic clocks and accelerometers would lead to more precise timekeeping and navigation systems, such as those used in global positioning systems, in defense and in broadcast communications. Ultraprecise clocks are also used in finance and trading.

“GPS tells me where I am to about a meter right now,” Kasevich said. “But what if I wanted to know where I was to within 10 centimeters? That’s what the impact of better clocks would be.”

A note on ultraprecise clocks

One can mark the passage of time by counting the number of pulses in an electromagnetic wave, just as you would count the ticks of a clock. If you know that a particular wave pulses 6 billion times per second, you know that, once you count 6 billion crests of the wave, one second has passed. So knowing the exact frequency of a microwave gives one a precise way to track time.

How it works

The entanglement: Rubidium atoms, trapped inside a cavity, are separated into two groups of about 100,000 atoms each. The groups sit between two mirrors. Light is made to bounce back and forth between the mirrors, tracing its way through the groups of atoms with every shot. The ricocheting light entangles them.

The sensing: A microwave ripples through the two groups of atoms. The atoms that happen to resonate with the microwave’s particular frequency respond by changing to a different state, like the wine glass that vibrates when a soprano hits just the right note.

Similarly, when a particular acceleration is applied to the atomic groups, some fraction of the atoms in each group responds by changing state.

The measurement: The two entangled atomic groups behave like two faces of a single clock, or two readings of one accelerometer.

The research team measured the number of atoms that changed state — the ones that vibrated like a wine glass — in each group.

Then they used the numbers to calculate the difference in the microwave frequencies applied to the two groups, and therefore the difference in the groups’ readings of time or acceleration.

Increased precision: The Kasevich team found that entanglement improves the precision in the frequency or acceleration difference read by the displays.

In their setup, the measurement of time in two locations was 3.5 times more precise when the clocks were entangled than if they were operating independently. For acceleration, the measurement was 1.2 times more precise with entanglement.

Impact

“If you want to know how long something takes, you might look at one clock as a starting point and then run to another room to look at another clock, the end point,” Kasevich said. “Our method exploits the entanglement principle to make that comparison as precise as possible.”

The researchers also successfully networked four groups of atoms in four separate locations using this configuration.

In the team’s experiment, the two groups of atoms were separated by about 20 micrometers, close to the average width of a human hair.

Their work means that time or acceleration can be compared, with unprecedented sensitivity, between four separate, albeit close-together, locations.

“In the future, we want to push them out to longer distances. The world wants clocks whose time can be compared. It’s the same with accelerometers. There are sensing configurations where you want to be able to read out the difference in the acceleration of one group with respect to another. We were able to show how to do that,” Kasevich said.

“This is a tour de force result from Mark and his team,” said Q-NEXT Deputy Director JoAnne Hewett, who is also the SLAC National Accelerator Laboratory associate director of fundamental physics and chief research officer as well as a Stanford professor of particle physics and astrophysics. “This means we can harness entanglement to develop sensors that are far more powerful than those we use today. We are another step closer to wielding quantum phenomena to improve our everyday lives.”

This work was supported by the DOE’s Office of Science National Quantum Information Science Research Centers as part of the Q-NEXT center.
