Contents
 1 Introduction, Class 1  Tuesday, May 7
 2 Sampling (Generating random numbers), Class 2  Thursday, May 9
 3 Summary of Multiplicative Congruential Algorithm
 4 (Generating random numbers continue) Class 3  Tuesday, May 14
 5 Summary of Inverse Transform Method
 6 Class 4  Thursday, May 16
 7 Class 5  Tuesday, May 21
 8 AcceptanceRejection Method
 9 Class 6  Thursday, May 23
 10 Class 7  Tuesday, May 28
 11 Class 8  Thursday, May 30, 2013
 12 Class 9  Tuesday, June 4, 2013
 13 Class 10  Thursday June 6th 2013
 14 Class 11  Tuesday，June 11, 2013
Introduction, Class 1  Tuesday, May 7
Course Instructor: Ali Ghodsi
Lecture:
001: TTh 8:309:50 MC1085
002: TTh 1:002:20 DC1351
Tutorial:
2:303:20 Mon M3 1006
Midterm
Monday June 17 2013 from 2:303:30
TA(s):
TA  Day  Time  Location

Lu Cheng  Monday  3:305:30 pm  M3 3108, space 2
Han ShengSun  Tuesday  4:006:00 pm  M3 3108, space 2
Yizhou Fang  Wednesday  1:003:00 pm  M3 3108, space 1
Huan Cheng  Thursday  3:005:00 pm  M3 3111, space 1
Wu Lin  Friday  11:001:00 pm  M3 3108, space 1
Four Fundamental Problems
1. Classification: Given an input object X, we have a function which will take in this input X and identify which 'class (Y)' it belongs to (Discrete Case)
i.e taking value from x, we could predict y.
(For example, an image of a fruit can be classified, through some sort of algorithm to be a picture of either an apple or an orange.)
2. Regression: Same as classification but in the continuous case except y is discrete. (Non discrete case)
3. Clustering: Use common features of objects in same class or group to form clusters.(in this case, x is given, y is unknown)
4. Dimensionality Reduction (aka Feature extraction, Manifold learning): Used when we have a variable in high dimension space and we want to reduce the dimension
Applications
Most useful when structure of the task is not well understood but can be characterized by a dataset with strong statistical regularity
Examples:
 Computer Vision, Computer Graphics, Finance (fraud detection), Machine Learning
 Search and recommendation (eg. Google, Amazon)
 Automatic speech recognition, speaker verification
 Text parsing
 Face identification
 Tracking objects in video
 Financial prediction(e.g. credit cards)
 Fraud detection
 Medical diagnosis
Course Information
Prerequisite: (One of CS 116, 126/124, 134, 136, 138, 145, SYDE 221/322) and (STAT 230 with a grade of at least 60% or STAT 240) and (STAT 231 or 241)
Antirequisite: CM 361/STAT 341, CS 437, 457
General Information
 No required textbook
 Recommended: "Simulation" by Sheldon M. Ross
 Computing parts of the course will be done in Matlab, but prior knowledge of Matlab is not essential (will have a tutorial on it)
 First midterm will be held on Monday, June 17 from 2:30 to 3:30
 Announcements and assignments will be posted on Learn.
 Other course material on: http://wikicoursenote.com/wiki/
 Log on to both Learn and wikicoursenote frequently.
 Email all questions and concerns to UWStat340@gmail.com. Do not use your personal email address! Do not email instructor or TAs about the class directly to theri personal accounts!
Wikicourse note (10% of final mark):
When applying an account in the wikicourse note, please use the quest account as your login name while the uwaterloo email as the registered email. This is important as the quest id will use to identify the students who make the contributions.
Example:
User: questid
Email: questid@uwaterloo.ca
After the student has made the account request, do wait for several hours before students can login into the account using the passwords stated in the email. During the first login, students will be ask to create a new password for their account.
As a technical/editorial contributor: Make contributions within 1 week and do not copy the notes on the blackboard.
Must do both All contributions are now considered general contributions you must contribute to 50% of lectures for full marks
 A general contribution can be correctional (fixing mistakes) or technical (expanding content, adding examples, etc) but at least half of your contributions should be technical for full marks
Do not submit copyrighted work without permission, cite original sources. Each time you make a contribution, check mark the table. Marks are calculated on honour system, although there will be random verifications. If you are caught claiming to contribute but didn't, you will lose marks.
Wikicoursenote contribution form : [1]
 you can submit your contributions in multiple times.
 you will be able to edit the response right after submitting
 send email to make changes to an old response : uwstat340@gmail.com
Tentative Topics
 Random variable and stochastic process generation
 DiscreteEvent Systems
 Variance reduction
 Markov Chain Monte Carlo
Tentative Marking Scheme
Item  Value

Assignments (~6)  30%
WikiCourseNote  10%
Midterm  20%
Final  40%
The final exam is going to be closed book and only nonprogrammable calculators are allowed
A passing mark must be achieved in the final to pass the course
Sampling (Generating random numbers), Class 2  Thursday, May 9
Introduction
Some people believe that sampling activities such as rolling a dice and flipping a coin are not truly random but are deterministic, since the result can be reliably calculated using things such as physics and math. In general, a deterministic model produces specific results given certain inputs by the model user, contrasting with a stochastic model which encapsulates randomness and probabilistic events.
A computer cannot generate truly random numbers because computers can only run algorithms, which are deterministic in nature. They can, however, generate Pseudo Random Numbers; numbers that seem random but are actually deterministic. Although the pseudo random numbers are deterministic, these numbers have a sequence of value and all of them have the appearances of being independent uniform random variables. Being deterministic, pseudo random numbers are valuable and beneficial due to the ease to generate and manipulate.
When people do the test for many times, the results will be closed the express values,that makes the trial looks like deterministic, however for each trial, the result is random. So, it looks like pseudo random numbers.
Mod
Let [math]n \in \N[/math] and [math]m \in \N^+[/math], then by Division Algorithm,
[math]\exists q, \, r \in \N \;\text{with}\; 0\leq r \lt m, \; \text{s.t.}\; n = mq+r[/math],
where [math]q[/math] is called the quotient and [math]r[/math] the remainder. Hence we can define a binary function
[math]\mod : \N \times \N^+ \rightarrow \N [/math] given by [math]r:=n \mod m[/math] which means take the remainder after division by m.
We say that n is congruent to r mod m if n = mq + r, where m is an integer.
if y = ax + b, then [math]b:=y \mod a[/math].
4.2 = 3 * 1.1 + 0.9 mod 1.1
0.9 = 4.2 mod 1.1
For example:
30 = 4 * 7 + 2 mod 7
2 = 30 mod 7
25 = 8 * 3 + 1 mod 3
1 = 25 mod 3
Note: [math]\mod[/math] here is different from the modulo congruence relation in [math]\Z_m[/math], which is an equivalence relation instead of a function.
mod can figure out one integer can be divided by another integer with no remainder or not. But both two integer should follow function: n = mq + r. m, r, q n are all integer. and r is smaller than q.
Multiplicative Congruential Algorithm
This is a simple algorithm used to generate uniform pseudo random numbers. It is also referred to as the Linear Congruential Method or Mixed Congruential Method. We define the Linear Congruential Method to be [math]x_{k+1}=(ax_k + b) \mod m[/math], where [math]x_k, a, b, m \in \N, \;\text{with}\; a, m \gt 0[/math]. ( [math]\mod m[/math] means taking the remainder after division by m) Given a "seed"(all integers and an initial value [math].x_0[/math] called seed) [math].(x_0 \in \N[/math], we can obtain values for [math]x_1, \, x_2, \, \cdots, x_n[/math] inductively. The Multiplicative Congruential Method may also refer to the special case where [math]b=0[/math].
An interesting fact about Linear Congruential Method is that it is one of the oldest and bestknown pseudorandom number generator algorithms. It is very fast and requires minimal memory to retain state. However, this method should not be used for applications where highquality randomness is required. They should not be used for Monte Carlo simulation and cryptographic applications. (Monte Carlo simulation will consider possibilities for every choice of consideration, and it shows the extreme possibilities. This method is not precise enough.)
First consider the following algorithm
[math]x_{k+1}=x_{k} \mod m[/math]
Example
[math]\text{Let }x_{k}=10,\,m=3[/math]
 [math]\begin{align} x_{1} &{}= 10 &{}\mod{3} = 1 \\ x_{2} &{}= 1 &{}\mod{3} = 1 \\ x_{3} &{}= 1 &{}\mod{3} =1 \\ \end{align}[/math]
[math]\ldots[/math]
Excluding x0, this example generates a series of ones. In general, excluding x0, the algorithm above will always generate a series of the same number less than M. Hence, it has a period of 1. We can modify this algorithm to form the Multiplicative Congruential Algorithm.
Multiplicative Congruential Algorithm
[math]x_{k+1}=(a \cdot x_{k} + b) \mod m [/math](a little tip: (a*b)mod c = (a mod c)*(b mod c))
Example
[math]\text{Let }a=2,\, b=1, \, m=3, \, x_{0} = 10[/math]
[math]\begin{align}
\text{Step 1: } 0&{}=(2\cdot 10 + 1) &{}\mod 3 \\
\text{Step 2: } 1&{}=(2\cdot 0 + 1) &{}\mod 3 \\
\text{Step 3: } 0&{}=(2\cdot 1 + 1) &{}\mod 3 \\
\end{align}[/math]
[math]\ldots[/math]
This example generates a sequence with a repeating cycle of two integers.
(If we choose the numbers properly, we could get a sequence of "random" numbers. However, how do we find the value of [math]a,b,[/math] and [math]m[/math]? At the very least [math]m[/math] should be a very large, preferably prime number. The larger [math]m[/math] is, the higher possibility people get a sequence of "random" numbers. This is easier to solve in Matlab. In Matlab, the command rand() generates random numbers which are uniformly distributed in the interval (0,1)). Matlab uses [math]a=7^5, b=0, m=2^{31}1[/math] – recommended in a 1988 paper, "Random Number Generators: Good Ones Are Hard To Find" by Stephen K. Park and Keith W. Miller (Important part is that [math]m[/math] should be large and prime)
MatLab Instruction for Multiplicative Congruential Algorithm:
Before you start, you need to clear all existing defined variables and operations:
>>clear all >>close all
>>a=17 >>b=3 >>m=31 >>x=5 >>mod(a*x+b,m) ans=26 >>x=mod(a*x+b,m)
(Note:
1. Keep repeating this command over and over again and you will seem to get random numbers – this is how the command rand works in a computer.
2. There is a function in MATLAB called RAND to generate a number between 0 and 1.
3. If we would like to generate 1000 and more numbers, we could use a for loop)
(Note on MATLAB commands:
1. clear all: clears all variables.
2. close all: closes all figures.
3. who: displays all defined variables.
4. clc: clears screen.)
>>a=13 >>b=0 >>m=31 >>x(1)=1 >>for ii=2:1000 x(ii)=mod(a*x(ii1)+b,m); end >>size(x) ans=1 1000 >>hist(x)
(Note: The semicolon after the x(ii)=mod(a*x(ii1)+b,m) ensures that Matlab will not print the entire vector of x. It will instead calculate it internally and you will be able to work with it. Adding the semicolon to the end of this line reduces the run time significantly.)
This algorithm involves three integer parameters [math]a, b,[/math] and [math]m[/math] and an initial value, [math]x_0[/math] called the seed. A sequence of numbers is defined by [math]x_{k+1} = ax_k+ b \mod m[/math]. [math]\mod m[/math] means taking the remainder after division by [math]m[/math].
Note: For some bad [math]a[/math] and [math]b[/math], the histogram may not look uniformly distributed.
Note: In MATLAB, hist(x) will generate a graph representing the distribution. Use this function after you run the code to check the real sample distribution.
Example: [math]a=13, b=0, m=31[/math]
The first 30 numbers in the sequence are a permutation of integers from 1 to 30, and then the sequence repeats itself so it is important to choose [math]m[/math] large to decrease the probability of each number repeating itself too early. Values are between [math]0[/math] and [math]m1[/math]. If the values are normalized by dividing by [math]m1[/math], then the results are approximately numbers uniformly distributed in the interval [0,1]. There is only a finite number of values (30 possible values in this case). In MATLAB, you can use function "hist(x)" to see if it looks uniformly distributed. We saw that the values between 030 had the same frequency in the histogram, so we can conclude that they are uniformly distributed.
If [math]x_0=1[/math], then
 [math]x_{k+1} = 13x_{k}\mod{31}[/math]
So,
 [math]\begin{align} x_{0} &{}= 1 \\ x_{1} &{}= 13 \times 1 + 0 &{}\mod{31} = 13 \\ x_{2} &{}= 13 \times 13 + 0 &{}\mod{31} = 14 \\ x_{3} &{}= 13 \times 14 + 0 &{}\mod{31} =27 \\ \end{align}[/math]
etc.
For example, with [math]a = 3, b = 2, m = 4, x_0 = 1[/math], we have:
 [math]x_{k+1} = (3x_{k} + 2)\mod{4}[/math]
So,
 [math]\begin{align}
x_{0} &{}= 1 \\
x_{1} &{}= 3 \times 1 + 2 \mod{4} = 1 \\
x_{2} &{}= 3 \times 1 + 2 \mod{4} = 1 \\
\end{align}[/math]
etc.
FAQ:
1.Why in the example above is 1 to 30 not 0 to 30?
[math]b = 0[/math] so in order to have [math]x_k[/math] equal to 0, [math]x_{k1}[/math] must be 0 (since [math]a=13[/math] is relatively prime to 31). However, the seed is 1. Hence, we will never observe 0 in the sequence.
Alternatively, {0} and {1,2,...,30} are two orbits of the left multiplication by 13 in the group [math]\Z_{31}[/math].
2.Will the number 31 ever appear?Is there a probability that a number never appears?
The number 31 will never appear. When you perform the operation [math]\mod m[/math], the largest possible answer that you could receive is [math]m1[/math]. Whether or not a particular number in the range from 0 to [math]m  1[/math] appears in the above algorithm will be dependent on the values chosen for [math]a, b[/math] and [math]m[/math].
Examples:[From Textbook]
If [math]x_0=3[/math] and [math]x_n=(5x_{n1}+7)\mod 200[/math], find [math]x_1,\cdots,x_{10}[/math].
Solution:
[math]\begin{align}
x_1 &{}= (5 \times 3+7) &{}\mod{200} &{}= 22 \\
x_2 &{}= 117 &{}\mod{200} &{}= 117 \\
x_3 &{}= 592 &{}\mod{200} &{}= 192 \\
x_4 &{}= 2967 &{}\mod{200} &{}= 167 \\
x_5 &{}= 14842 &{}\mod{200} &{}= 42 \\
x_6 &{}= 74217 &{}\mod{200} &{}= 17 \\
x_7 &{}= 371092 &{}\mod{200} &{}= 92 \\
x_8 &{}= 1855467 &{}\mod{200} &{}= 67 \\
x_9 &{}= 9277342 &{}\mod{200} &{}= 142 \\
x_{10} &{}= 46386717 &{}\mod{200} &{}= 117 \\
\end{align}[/math]
Comments:
Typically, it is good to choose [math]m[/math] such that [math]m[/math] is large, and [math]m[/math] is prime. Careful selection of parameters '[math]a[/math]' and '[math]b[/math]' also helps generate relatively "random" output values, where it is harder to identify patterns. For example, when we used a composite (non prime) number such as 40 for [math]m[/math], our results were not satisfactory in producing an output resembling a uniform distribution.
The computed values are between 0 and [math]m1[/math]. If the values are normalized by dividing by [math]m1[/math], their result is numbers uniformly distributed on the interval [math]\left[0,1\right][/math] (similar to computing from uniform distribution).
From the example shown above, if we want to create a large group of random numbers, it is better to have large [math]m[/math] so that the random values generated will not repeat after several iterations.
There has been a research about how to choose uniform sequence. Many programs give you the options to choose the seed. Sometimes the seed is chosen by CPU.
this part i learnt how to use R code to figure out the relationship between two ingeter
division, and their remainder. And when we use R to calculate R with random variables for a range such as(1:1000),the graph of distribution is like uniform distribution.
Summary of Multiplicative Congruential Algorithm
Problem: generate Pseudo Random Numbers.
Plan:
 find integer: a b m(large prime) </i>x_{0}</i>(the seed) .
 [math]x_{x+1}=(ax_{k}+b)[/math]mod m
 Note: These steps can be found in Simulation 5th Ed. by Sheldon Ross.
 [math]P(X\leq x)[/math]
 [math] F(x)= \begin{cases} 0 & \text{for }x \lt a \\[8pt] \frac{xa}{ba} & \text{for }a \le x \lt b \\[8pt] 1 & \text{for }x \ge b \end{cases} [/math]
 [math]\begin{align}P(X = x_i) &{}= p_i \end{align}[/math]
 [math]x_0 \leq x_1 \leq x_2 \dots \leq x_n[/math]
 [math]\sum p_i = 1[/math]
 [math]\begin{align} P(X = 0) &{}= 0.5\\ P(X = 1) &{}= 0.5\\ \end{align}[/math]
 [math] x = \begin{cases} 0, & \text{if } U\leq 0.5 \\ 1, & \text{if } 0.5 \lt U \leq 1 \end{cases}[/math]
 Code
 [math]\begin{align} P(X = 0) &{}= 0.3 \\ P(X = 1) &{}= 0.2 \\ P(X = 2) &{}= 0.5 \end{align}[/math]
 [math] F(x) = \begin{cases} 0, & \text{if } x \lt 0 \\ 0.3, & \text{if } x \lt 1 \\ 0.5, & \text{if } x \lt 2 \\ 1, & \text{if } x \ge 2 \end{cases}[/math]
 [math] x = \begin{cases} 0, & \text{if } U\leq 0.3 \\ 1, & \text{if } 0.3 \lt U \leq 0.5 \\ 2, & \text{if } 0.5 \lt U\leq 1 \end{cases}[/math]
 Code (as shown in class)
 [math] f_{x}(x) = \begin{cases} 2x, & \text{if } 0\leq x \leq 1 \\ 0, & \text{if } otherwise \end{cases}[/math]
 [math] F_{x}(x) = \begin{cases} 0, & \text{if } x \lt 0 \\ \int_{0}^{x}2sds = x^{2}, & \text{if } 0\leq x \leq 1 \\ 1, & \text{if } x \gt 1 \end{cases}[/math]
 [math]\begin{align} U = x^{2}, X = F^{1}x(U)= U^{\frac{1}{2}}\end{align}[/math]
 [math]\begin{align} P(X = 1) = p, P(X = 0) = 1  p\end{align}[/math]
 [math] F(x) = \begin{cases} 1p, & \text{if } x \lt 1 \\ 1, & \text{if } x \ge 1 \end{cases}[/math]
 [math]\begin{align} f(x) = \frac {\, e^{u} u^x}{x!} \end{align}[/math]
 [math]\begin{align} P_{x+1} = \frac {\, e^{u} u^{x+1}}{(x+1)!} \end{align}[/math]
 [math] x = \begin{cases} 1, & \text{if } U\leq p \\ 2, & \text{if } p \lt U \leq 1(1p)^2 \\ 3, & \text{if } 1(1p)^2 \lt U\leq 1(1p)^3 \\ .... k, & \text{if } 1(1p)^{k1} \lt U\leq 1(1p)^k .... \end{cases}[/math]
 find CDF F
 find the inverse F^{1}
 Generate a list of uniformly distributed number {x}
 {F^{1}(x)} is what we want
 generate a list of uniformly distributed number {u}
 d_{i}=x_{i} if[math] X=x_i, [/math] if [math] F(x_{i1})\lt U\leq F(x_i) [/math]
 {d_{i}=x_{i}} is what we want
 Not all functions have inverse functions (ie, the range of x and y have limit and do not fix the inverse functions)
 For some distributions, such as Gaussian, it is too difficult to find the inverse
 Draw Y~g(.)
 Draw U~u(0,1) (Note: U and Y are independent)
 If [math]u\leq \frac{f(y)}{cg(y)}[/math] (which is [math]P(acceptedy)[/math]) then x=y, else return to Step 1
 When we want to find a target distribution, denoted as [math]f(x)[/math]; we need to first find a proposal distribution [math]g(x)[/math] which is easy to sample from.
The area of the f(x) is under the area of the g(x).  The relationship between the proposal distribution and target distribution is: [math] c \cdot g(x) \geq f(x) [/math].
 Chance of acceptance is less if the distance between [math]f(x)[/math] and [math] c \cdot g(x)[/math] is big, and viceversa, [math] c [/math] keeps [math] \frac {f(x)}{c \cdot g(x)} [/math] below 1 (so [math]f(x) \leq c \cdot g(x)[/math]), and we must to choose the constant [math] C [/math] to achieve this.
 In other words, [math]C[/math] is chosen to make sure [math] c \cdot g(x) \geq f(x) [/math]. However, it will not make sense if [math]C[/math] is simply chosen to be arbitrarily large. We need to choose [math]C[/math] such that [math]c \cdot g(x)[/math] fits [math]f(x)[/math] as tightly as possible.
 The constant c can not be negative number.
 The logic behind this:
 For this method to be efficient, the constant c must be selected so that the rejection rate is low.(The efficiency for this method is[math]\left ( \frac{1}{c} \right )[/math])
 It is easy to show that the expected number of trials for an acceptance is c. Thus, the smaller the c is, the lower the rejection rate, and the better the algorithm:
 recall the acceptance rate is 1/c.(not rejection rate)
 Let [math]X[/math] be the number of trials for an acceptance, [math] X \sim~ Geo(\frac{1}{c})[/math]
 [math]\mathbb{E}[X] = \frac{1}{\frac{1}{c}} = c [/math]
 The number of trials needed to generate a sample size of [math]N[/math] follows a negative binomial distribution. The expected number of trials needed is then [math]cN[/math].
 So far, the only distribution we know how to sample from is the UNIFORM distribution.
 Let [math]Y \sim~ g(y)[/math]
 Let [math]U \sim~ Unif [0,1] [/math]
 If [math]U \leq \frac{f(x)}{c \cdot g(x)}[/math] then X=Y; else return to step 1 (This is not the way to find C. This is the general procedure.)
 Draw y~u(0,1)
 Draw u~u(0,1)
 if [math]u \leq \frac{(2\cdot y)}{(2\cdot 1)}, u \leq y,[/math] then [math] x=y[/math]
 Else go to Step 1
 *Note: The reason that a for loop is not used is that we need continue the looping until we get 1000 successful samples. We will reject some samples during the process and therefore do not know the number of y we are going to generate.
 *Note2: In this example, we used c=2, which means we accept half of the points we generate on average. Generally speaking, 1/c would be the probability of acceptance, and an indicator of the efficiency of your chosen proposal distribution and algorithm.
 *Note3: We use while instead of for when looping because we do not know how many iterations are required to generate 1000 successful samples.
 *Note4: If c=1, we will accept all points, which is the ideal situation.
 1: Draw U1 ~ U(0,1)
 2: Draw U2~U(0,1)
 3: let [math] y = U1*2  1 [/math]
 4: if [math]U2 \leq \frac { \frac{3}{4} * (1y^2)} { \frac{3}{4}} = {1y^2}[/math], then x=y, note that (3/4(1y^2)/(3/4) is getting from f(y) / (cg(y)) )
 5: else: return to step 1
 [math]F(x)=\int_0^x \! 2s\,ds={x^2} 0={x^2}[/math]
 [math]y=x^2[/math]
 [math]x=\sqrt y[/math]
 [math] F^{1}\left (\, x \, \right) =\sqrt x[/math]
 Procedure
 1: Draw [math] U~ \sim~ Unif [0,1] [/math]
 2: [math] x=F^{1}\left (\, u\, \right) =\sqrt u[/math]
 Note: Y= R(2U1)
 Code
 Example 1
 [math]c = max \frac{f(x)}{g(x)} = \frac {0.3}{0.2} = 1.5 [/math]
 [math]\frac{p(x)}{cg(x)} = \frac{p(x)}{1.5*0.2} = \frac{p(x)}{0.3} [/math]
 Code for example 1
 Example 2
 Code for example 2
 Example 3
 Example 4 (Hypergeometric & Binomial)
 Draw y~g(.)
 Draw u~Unif(0,1)
 If [math]u\leq \frac{f(y)}{cg(y)}[/math]then set x=y. Else return to Step 1
 Gamma
 Additive Property
 Procedure
 Sample independently from a uniform distribution [math]t[/math] times, giving [math] U_1,\dots,U_t \sim~ U(0,1)[/math]
 Use the Inverse Transform Method, [math] X_i = \frac {1}{\lambda}\log(1U_i)[/math], giving [math] X_1,\dots,X_t \sim~Exp(\lambda)[/math]
 Use the additive property,[math] X = \Sigma_{i=1}^t X_i \sim~ Gamma (t, \lambda) [/math]
 Note for Procedure
 If [math]U\sim~U(0,1)[/math], then [math]U[/math] and [math]1U[/math] will have the same distribution (both follows [math]U(0,1)[/math])
 This is because the range for [math]1U[/math] is still [math](0,1)[/math], and their densities are identical over this range.
 Let [math]Y=1U[/math], [math]Pr(Y\lt =y)=Pr(1U\lt =y)=Pr(U\gt =1y)=1Pr(U\lt =1y)=1(1y)=y[/math], thus [math]1U\sim~U(0,1)[/math]
 Code
 Code
 From cartesian to polar coordinates
 X(1,:) returns the first row
 X(:,1) returns the first column
 X(i,i) returns the (i,i)th entry
 sum(X,1) or sum(X) is a summation of the rows of X, sum(X) also does the same thing. The output is a row vector of the sums of each column.
 sum(X,2) is a summation of the columns of X, returning a vector.
 rand(r,c) will generate random numbers in r row and c columns
 The dot operator (.), when placed before a function, such as +,,^, *, and many others specifies to apply that function to every element of a vector or a matrix. For example, to add a constant c to elements of a matrix A, do A.+c as opposed to simply A+c. The dot operator is not required for functions that can only take a number as their input (such as log).
 Matlab processes loops very slowly, while it is fast with matrices and vectors, so it is preferable to use the dot operator to and matrices of random numbers than loops if it is possible.
 X(1,:) returns the first row
 [math]f(x) = \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} x^2}[/math]
 Warning : the General Normal distribution is
 N(0,1) is standard normal. [math] \mu [/math] =0 and [math] \sigma [/math]=1
 1. Be a positive number (as it is a length)
 2. It must be from a distribution that has more data points closer to the origin so that as we go further from the origin, less points are generated (the two options are Chisquared and Exponential distribution)
 R^{2}= X^{2}+Y^{2} and [math] \tan(\theta) = \frac{y}{x} [/math] where X and Y are two independent standard normal
 [math]f(x) = \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} x^2}[/math]
 [math]f(y) = \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} y^2}[/math]
 [math]f(x,y) = \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} x^2} * \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} y^2}=\frac{1}{2\pi}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} (x^2+y^2)} [/math]
 Since for independent distributions, their joint probability function is the multiplication of two independent probability functions  [math]\begin{matrix} f(d,\theta) = \frac{1}{2}e^{\frac{d}{2}}*\frac{1}{2\pi},\quad d = R^2 \end{matrix},\quad for\quad 0\leq d\lt \infty\ and\quad 0\leq \theta\leq 2\pi [/math]
 [math] \begin{align} R^2 = x^2 + y^2 \end{align} [/math]
 [math] \tan(\theta) = \frac{y}{x} [/math]
 Below is the proof:
 [math]\operatorname{E}[X]= \;\int_{\infty}^{\infty} x \frac{1}{\sqrt{2\pi}} e^{x^2/2} \, dx.[/math]
 [math]\phi(x) = \frac{1}{\sqrt{2\pi}}\, e^{ \frac{\scriptscriptstyle 1}{\scriptscriptstyle 2} x^2}.[/math]
 [math]=\;\int_{\infty}^{\infty} x \phi(x), dx.[/math]
 Since the first derivative ϕ′(x) is −xϕ(x)
 [math]=\;\  \int_{\infty}^{\infty} \phi'(x), dx.[/math]
 [math]=  \left[\phi(x)\right]_{\infty}^{\infty}[/math]
 [math]= 0[/math]
 Procedure (BoxMuller Transformation Method):
 Code
 Code
 The pdf of the general normal distribution is
 Code
 Generate a sample u from Norm(0, 1) using the BoxMuller transform.
 Set v = a + bu.
 [math]\displaystyle u_i[/math] is the average of [math]\displaystyle z_i[/math]
 [math]\!\Sigma_{ii}[/math] is the variance of [math]\displaystyle z_i[/math]
 [math]\!\Sigma_{ij}[/math] is the covariance of [math]\displaystyle z_i[/math] and [math]\displaystyle z_j[/math]
 Generate an n by 1 vector [math]\mathbf{x} = \begin{bmatrix}x_{1} & x_{2} & ... & x_{n}\end{bmatrix}[/math] where [math]x_{i}[/math] ~ Norm(0, 1) using the BoxMuller transform.
 Calculate [math]\!\Sigma^{1/2}[/math] using singular value decomposition.
 Set [math]\mathbf{z} = \Sigma^{1/2} \mathbf{x} + \mathbf{u}[/math].
 Code to Generate Bernoulli(p = 0.3)
 Code to Generate Binomial(n = 10,p = 0.3)
 [math]\displaystyle \text{Beta}(\alpha,\beta) = \frac{\Gamma(\alpha+\beta)}{\Gamma(\alpha)\Gamma(\beta)}x^{\alpha1}(1x)^{\beta1} [/math] where [math]0 \leq x \leq 1[/math] and [math]\alpha[/math]>0, [math]\beta[/math]>0
 [math]\displaystyle \text{Beta}(1,1) = \frac{\Gamma(1+1)}{\Gamma(1)\Gamma(1)}x^{11}(1x)^{11}[/math]
 [math] = \frac{1!}{0!0!}x^{0}(1x)^{0}[/math]
 [math] = 1 [/math]
 [math]\displaystyle \text{Beta}(1,1) = U (0, 1) [/math]
 [math]\displaystyle \text{f}(x) = \frac{\Gamma(1+\beta)}{\Gamma(1)\Gamma(\beta)}x^{11}(1x)^{\beta1}=\beta(1x)^{\beta1}[/math]
 [math]\beta=1 [/math]
 [math]\displaystyle \text{f}(x) = \frac{\Gamma(\alpha+1)}{\Gamma(\alpha)\Gamma(1)}x^{\alpha1}(1x)^{11}=\alpha x^{\alpha1}[/math]
 1. Generate U~Unif(0,1)<br\>
 2. Assign [math]x = u^\frac {1}{\alpha}[/math]
 if [math]Y_1[/math] follows gamma [math](\alpha,1)[/math]<br\>
 [math]Y_2[/math] follows gamma [math](\beta,1)[/math]<br\>
 then [math]Y=\frac {Y_1}{Y_1+Y_2}[/math] follows Beta [math](\alpha,\beta)[/math]<br\>
 1. Sample from Y1 ~ Gamma ([math]\alpha[/math],1)<br\>
 2. Sample from Y2 ~ Gamma ([math]\beta[/math],1)<br\>
 3. Set
 [math] Y = \frac{Y_1}{Y_1+Y_2}[/math]
 ie. If late for class=[math]x_1[/math] and sick=[math]x_2[/math], then these are dependent variables so can only use equation 1 ([math]f(x) = f(x_1, x_2)= f(x_1) f(x_2x_1)[/math])
 ie. If late for class=[math]x_1[/math] and milk is white=[math]x_2[/math], then these are independent variables so can use both equations 1 and 2.
 Note: x_{i} = a_{i} + U(b_{i}a_{i}) denotes X_{i} ~U(a_{i},b_{i})
 We know the radius is 1
 Then the area of the square is [math](1(1))^2=4[/math]<br\>
 Then the area of the circle is [math]\pi[/math]<br\>
 [math]\pi[/math] is approximated to be [math]4\times c=4 \times 0.7839=3.1356[/math] in the above example <br\>
 [math]\!f(n)= \frac{\lambda^n e^{\lambda}}{n!} \qquad n= 0,1,\ldots,[/math]
</ol> Matlab Instruction:
>>clear all >>close all >>a=17 >>b=3 >>m=31 >>x=5 >>mod(a*x+b,m) ans=26 >>x=mod(a*x+b,m)
</div>
Inverse Transform Method
This method is useful for generating types of distribution other than uniform distribution, such as exponential distribution and normal distribution. However, to easily use this method in generating pseudorandom numbers, the probability distribution consumed must have a cumulative distribution function (cdf) [math]F[/math] with a tractable inverse [math]F^{1}[/math].
Theorem:
If we want to generate the value of a discrete random variable X, we must generate a random number U, uniformly distributed over (0,1).
Let [math]F:\R \rightarrow \left[0,1\right][/math] be a cdf. If [math]U \sim U\left[0,1\right][/math], then the random variable given by [math]X:=F^{1}\left(U\right)[/math]
follows the distribution function [math]F\left(\cdot\right)[/math],
where [math]F^{1}\left(u\right):=\inf F^{1}\big(\left[u,+\infty\right)\big) = \inf\{x\in\R  F\left(x\right) \geq u\}[/math] is the generalized inverse.
Note: [math]F[/math] need not be invertible, but if it is, then the generalized inverse is the same as the inverse in the usual case.
Proof of the theorem:
The generalized inverse satisfies the following:
[math]\begin{align}
\forall u \in \left[0,1\right], \, x \in \R, \\
&{} F^{1}\left(u\right) \leq x &{} \\
\Rightarrow &{} F\Big(F^{1}\left(u\right)\Big) \leq F\left(x\right) &&{} F \text{ is nondecreasing} \\
\Rightarrow &{} F\Big(\inf \{y \in \R  F(y)\geq u \}\Big) \leq F\left(x\right) &&{} \text{by definition of } F^{1} \\
\Rightarrow &{} \inf \{F(y) \in [0,1]  F(y)\geq u \} \leq F\left(x\right) &&{} F \text{ is right continuous and nondecreasing} \\
\Rightarrow &{} u \leq F\left(x\right) &&{} \text{by definition of } \inf \\
\Rightarrow &{} x \in \{y \in \R  F(y) \geq u\} &&{} \\
\Rightarrow &{} x \geq \inf \{y \in \R  F(y)\geq u \}\Big) &&{} \text{by definition of } \inf \\
\Rightarrow &{} x \geq F^{1}(u) &&{} \text{by definition of } F^{1} \\
\end{align}[/math]
That is [math]F^{1}\left(u\right) \leq x \Leftrightarrow u \leq F\left(x\right)[/math]
Finally, [math]P(X \leq x) = P(F^{1}(U) \leq x) = P(U \leq F(x)) = F(x)[/math], since [math]U[/math] is uniform on the unit interval.
This completes the proof.
Therefore, in order to generate a random variable X~F, it can generate U according to U(0,1) and then make the transformation x=[math] F^{1}(U) [/math]
Note that we can apply the inverse on both sides in the proof of the inverse transform only if the pdf of X is monotonic. A monotonic function is one that is either increasing for all x, or decreasing for all x.
Inverse Transform Algorithm for Generating Binomial(n,p) Random Variable
Step 1: Generate a random number [math]U[/math].
Step 2: [math]c = \frac {p}{(1p)}[/math], [math]i = 0[/math], [math]pr = (1p)^n[/math], [math]F = pr[/math]
Step 3: If U<F, set X = i and stop,
Step 4: [math] pr = \, {\frac {c(ni)}{(i+1)}} {pr}, F = F +pr, i = i+1[/math]
Step 5: Go to step 3
*
Example: [math] f(x) = \lambda e^{\lambda x}[/math]
[math] F(x)= \int_0^x f(t) dt[/math]
[math] = \int_0^x \lambda e ^{\lambda t}\ dt[/math]
[math] = \frac{\lambda}{\lambda}\, e^{\lambda t}\,  \underset{0}{x} [/math]
[math] = e^{\lambda x} + e^0 [/math]
[math] =1  e^{ \lambda x} [/math]
[math] y=1e^{ \lambda x} [/math]
[math] 1y=e^{ \lambda x}[/math]
[math] x=\frac {ln(1y)}{\lambda}[/math]
[math] y=\frac {ln(1x)}{\lambda}[/math]
[math] F^{1}(x)=\frac {ln(1x)}{\lambda}[/math]
Step 1: Draw U ~U[0,1];
Step 2: [math] x=\frac{ln(1U)}{\lambda} [/math]
Example:
[math] X= a + (ba),[/math] U is uniform on [a, b]
[math] x=\frac{ln(U)}{\lambda}[/math] is exponential with parameter [math] {\lambda} [/math]
Example 2:
Given a CDF of X: [math]F(x) = x^5[/math], transform U~U[0,1].
Sol:
Let [math]y=x^5[/math], solve for x: [math]x=y^\frac {1}{5}[/math]. Therefore, [math]F^{1} (x) = x^\frac {1}{5}[/math]
Hence, to obtain a value of x from F(x), we first set u as an uniform distribution, then obtain the inverse function of F(x), and set
[math]x= u^\frac{1}{5}[/math]
Matlab Code:
For this exponential distribution, we will let lambda be 2. Code: % Set up the parameters. lam = 2; n = 1000; % Generate the random variables. uni = rand(1,n); X = log(uni)/lam; % Get the values to draw the theoretical curve. x = 0:.1:5; % This is a fuction in the Statistics Toolbox. y = exppdf(x,1/2); % Get the information for the histogram. [N, h] = hist(X,10); % Change bar heights to make it correspond to the theoretical density. N = N/(h(2)h(1))/n; % Do the plots. bar(h,N,1,'w') % hold on retains the current plot and certain axes properties so that subsequent graphing commands add to the existing graph. hold on plot(x,y) % hold off resets axes properties to their defaults before drawing new plots. hold off is the default. hold off xlabel('X') ylabel('f(x)  Exponential')
Example 3:
Given u~U[0,1], generate x from BETA(1,β)
Solution:
[math]F(x)= 1(1x)^\beta[/math],
[math]u= 1(1x)^\beta[/math]
Solve for x:
[math](1x)^\beta = 1u[/math],
[math]1x = (1u)^\frac {1}{\beta}[/math],
[math]x = 1(1u)^\frac {1}{\beta}[/math]
Example 4Estimating pi:
Let's use rand() and Monte Carlo Method to estimate [math]pi[/math]
N= total number of points
Nc = total number of points inside the circle
Prob[(x,y) lies in the circle]=[math]Area of circle/Area of Square[/math]
If we take square of size 2, circle will have area pi.
Thus pi= [math]4*(Nc/N)[/math]
Matlab Code:
>>N=10000; >>Nc=0; >>a=0; >>b=2; >>for t=1:N x=a+(ba)*rand(); y=a+(ba)*rand(); if (x1)^2+(y1)^2<=1 Nc=Nc+1; end end >>4*(Nc/N) ans = 3.1380
In Matlab, you can use functions: "who" to see what variables you have defined "clear all" to clear all variables you have defined "close all" to close all figures
MatLab for Inverse Transform Method:
>>u=rand(1,1000); >>hist(u) #will generate a fairly uniform diagram
#let λ=2 in this example; however, you can make another value for λ >>x=(log(1u))/2; >>size(x) #1000 in size >>figure >>hist(x) #exponential
Limitations:
1. This method is flawed since not all functions are invertible or monotonic: generalized inverse is hard to work on.
2. It may be impractical since some CDF's and/or integrals are not easy to compute such as Gaussian distribution.
We learned how to prove the cdf transfer to inverse cdf,and use the uniform distribution to obtain a value of x from F(x). We also can use uniform distribution in inverse mothed to determine other distribution. The probability of getting a point for a circle over the triangle is a closed uniform distribution, each point in the circle and over the triangle is almost the same. and we can look at the graph to determine what kind of distribution the graph belongs to.
Probability Distribution Function Tool in MATLAB
disttool #shows different distributions
This command allows users to explore the effect of changes of parameters on the plot of either a CDF or PDF.
change the value of mu and sigma can change the graph skew side.
(Generating random numbers continue) Class 3  Tuesday, May 14
Recall the Inverse Transform Method
1. Draw U~U(0,1)
2. X = F^{1}(U)
Proof
First note that
[math]P(U\leq a)=a, \forall a\in[0,1][/math]
[math]= P(F^{1}(U)\leq x)[/math] (since [math]U[/math] has a uniform distribution)
[math]= P((F(F^{1}(U))\leq F(x))[/math] (since [math]F(\cdot )[/math] is monotonically increasing)
[math]= P(U\leq F(x)) [/math]
[math]= F(x) , \text{ where } 0 \leq F(x) \leq 1 [/math]
This is the c.d.f. of X.
Note: that the CDF of a U(a,b) random variable is:
Thus, for [math] U [/math] ~ [math]U(0,1) [/math], we have [math]P(U\leq 1) = 1[/math] and [math]P(U\leq 1/2) = 1/2[/math].
More generally, we see that [math]P(U\leq a) = a[/math].
For this reason, we had [math]P(U\leq F(x)) = F(x)[/math].
Reminder:
This is only for uniform distribution [math] U~ \sim~ Unif [0,1] [/math]
[math] P (U \le 1) = 1 [/math]
[math] P (U \le 0.5) = 0.5 [/math]
[math] P (U \le a) = a [/math]
Note that on a single point there is no mass probability (i.e. if [math]u[/math] <= 0.5, then 0.5> [math] u [/math], or if [math] u [/math] < 0.5, then 0.5 <= [math] u [/math]
LIMITATIONS OF THE INVERSE TRANSFORM METHOD
Though this method is very easy to use and apply, it does have disadvantages/limitations:
1. We have to find the inverse c.d.f function [math] F^{1}(\cdot) [/math] and make sure it is monotonically increasing, in some cases this function does not exist
2. For many distributions such as Gaussian, it is too difficult to find the inverse cdf function , making this method inefficient
Discrete Case
The same technique can be used for discrete case. We want to generate a discrete random variable x, that has probability mass function:
In general in the discrete case, we have [math]x_0, \dots , x_n[/math] where:
Algorithm for applying Inverse Transformation Method in Discrete Case (Procedure):
1. Define a probability mass function for [math]x_{i}[/math] where i = 1,....,k. Note: k could grow infinitely.
2. Generate a uniform random number U, [math] U~ \sim~ Unif [0,1] [/math]
3. If [math]U\leq p_{o}[/math], deliver [math]X = x_{o}[/math]
4. Else, if [math]U\leq p_{o} + p_{1} [/math], deliver [math]X = x_{1}[/math]
5. Repeat the process again till we reached to [math]U\leq p_{o} + p_{1} + ......+ p_{k}[/math], deliver [math]X = x_{k}[/math]
Example in class: (Coin Flipping Example)
We want to simulate a coin flip. We have U~U(0,1) and X = 0 or X = 1.
We can define the U function so that:
If U <= 0.5, then X = 0
and if 0.5 < U <= 1, then X =1.
This allows the probability of Heads occurring to be 0.5 and is a good generator of a random coin flip.
[math] U~ \sim~ Unif [0,1] [/math]
The answer is:
>>for ii=1:1000 u=rand; if u<0.5 x(ii)=0; else x(ii)=1; end end >>hist(x)
Note: The role of semicolon in Matlab: Matlab will not print out the results if the line ends in a semicolon and vice versa.
Example in class:
Suppose we have the following discrete distribution:
The cumulative distribution function (cdf) for this distribution is then:
Then we can generate numbers from this distribution like this, given [math]U \sim~ Unif[0, 1][/math]:
"Procedure"
1. Draw U~u (0,1)
2. if U<=0.3 deliver x=0
3. else if 0.3<U<=0.5 deliver x=1
4. else 0.5<U<=1 deliver x=2
Use Editor window to edit the code
>>close all >>clear all >>for ii=1:1000 u=rand; if u<=0.3 x(ii)=0; elseif u<=0.5 x(ii)=1; else x(ii)=2; end end >>size(x) >>hist(x)
Example: Generating a random variable from pdf
Example: Generating a Bernoulli random variable
1. Draw [math] U~ \sim~ Unif [0,1] [/math]
2. [math]
X = \begin{cases}
1, & \text{if } U\leq p \\
0, & \text{if } U \gt p
\end{cases}[/math]
Example: Generating a Poisson random variable
Let X ~ Poi(u). Write an algorithm to generate X. The PDF of a poisson is:
We know that
The ratio is [math]\begin{align} \frac {P_{x+1}}{P_x} = ... = \frac {u}{{x+1}} \end{align}[/math] Therefore, [math]\begin{align} P_{x+1} = \, {\frac {u}{x+1}} P_x\end{align}[/math]
Algorithm:
1) Generate U ~ U(0,1)
2) [math]\begin{align} X = 0 \end{align}[/math]
[math]\begin{align} F = P(X = 0) = e^{u}*u^0/{0!} = e^{u} = p \end{align}[/math]
3) If U<F, output x
Else, [math]\begin{align} p = (u/(x+1))^p \end{align}[/math]
[math]\begin{align} F = F + p \end{align}[/math]
[math]\begin{align} x = x + 1 \end{align}[/math]
4) Go to x
Acknowledgements: This is from Stat 340 Winter 2013
Example: Generating Geometric Distribution:
Consider Geo(p) where p is the probability of success, and define random variable X such that X is the number of failure before the first success. x=1,2,3..... We have pmf: [math]P(X=x_i) = \, p (1p)^{x_{i1}}[/math] We have CDF: [math]F(x)=P(X \leq x)=1P(X\gt x) = 1(1p)^x[/math], P(X>x) means we get at least x failures before observe the first success. Now consider the inverse transform:
Note: Unlike the continuous case, the discrete inversetransform method can always be used for any discrete distribution (but it may not be the most efficient approach)
General Procedure
1. Draw U ~ U(0,1)
2. If [math]U \leq P_{0}[/math] deliver [math]x = x_{0}[/math]
3. Else if [math]U \leq P_{0} + P_{1}[/math] deliver [math]x = x_{1}[/math]
4. Else if [math]U \leq P_{0} + P_{1} + P_{2} [/math] deliver [math]x = x_{2}[/math]
...
Else if [math]U \leq P_{0} + ... + P_{k} [/math] deliver [math]x = x_{k}[/math]
Problems
1. We have to find [math] F^{1} [/math]
2. For many distributions, such as Gaussian, it is too difficult to find the inverse of [math] F(x) ,[/math] flipping a coin is a discrete case of uniform distribution, and for the code it is randomly flipped 1000 times for the coin, and the result we can see is closed to the express value(0.5) and example 2 is another discrete distribution, it shows that we can discrete uniform for 3 part like ,0,1,2, and the probability of each part or each trial is the same. Example 3 is use inverse method to figure out the probability range of each random varibles.
Summary of Inverse Transform Method
Problem:generate types of distribution.
Plan:
Continuous case:
Matlab Instruction
>>u=rand(1,1000); >>hist(u) >>x=(log(1u))/2; >>size(x) >>figure >>hist(x)
Discrete case:
Matlab Instruction
>>for ii=1:1000 u=rand; if u<0.5 x(ii)=0; else x(ii)=1; end end >>hist(x)
AcceptanceRejection Method
Although the inverse transformation method does allow us to change our uniform distribution, it has two limits;
To generate random samples for these functions, we will use different methods, such as the AcceptanceRejection Method. This method is more efficient than the inverse transform method. The basic idea is to find an alternative probability distribution with density function f(x);
Suppose we want to draw random sample from a target density function f(x), x∈S_{x}, where S_{x} is the support of f(x). If we can find some constant c(≥1) (In practise, we prefer c as close to 1 as possible) and a density function g(x) having the same support S_{x} so that f(x)≤cg(x), ∀x∈S_{x}, then we can apply the procedure for AcceptanceRejection Method. Typically we choose a density function that we already know how to sample from for g(x).
{{
Template:namespace detect
 type = style  image =  imageright =  style =  textstyle =  text = This article may require cleanup to meet Wikicoursenote's quality standards. The specific problem is: Do not write [math]c*g(x)[/math]. Instead write [math]c \times g(x)[/math] or [math]\,c g(x)[/math]. Please improve this article if you can.  small =  smallimage =  smallimageright =  smalltext = }}
The main logic behind the AcceptanceRejection Method is that:
1. We want to generate sample points from an unknown distribution, say f(x).
2. We use cg(x) to generate points so that we have more points than f(x) could ever generate for all x. (where c is a constant, and g(x) is a known distribution)
3. For each value of x, we accept and reject some points based on a probability, which will be discussed below.
Note: If the red line was only g(x) as opposed to [math]\,c g(x)[/math] (i.e. c=1), then [math]g(x) \geq f(x)[/math] for all values of x if and only if g and f are the same functions. This is because the sum of pdf of g(x)=1 and the sum of pdf of f(x)=1, hence, [math]g(x) \ngeqq f(x)[/math] ∀x.
Also remember that [math]\,c g(x)[/math] always generates higher probability than what we need. Thus we need an approach of getting the proper probabilities.
c must be chosen so that [math]f(x)\leqslant c g(x)[/math] for all value of x. c can only equal 1 when f and g have the same distribution. Otherwise:
Either use a software package to test if [math]f(x)\leqslant c g(x)[/math] for an arbitrarily chosen c > 0, or:
1. Find first and second derivatives of f(x) and g(x).
2. Identify and classify all local and absolute maximums and minimums, using the First and Second Derivative Tests, as well as all inflection points.
3. Verify that [math]f(x)\leqslant c g(x)[/math] at all the local maximums as well as the absolute maximums.
4. Verify that [math]f(x)\leqslant c g(x)[/math] at the tail ends by calculating [math]\lim_{x \to +\infty} \frac{f(x)}{\, c g(x)}[/math] and [math]\lim_{x \to \infty} \frac{f(x)}{\, c g(x)}[/math] and seeing that they are both < 1. Use of L'Hopital's Rule should make this easy, since both f and g are p.d.f's, resulting in both of them approaching 0.
5.Efficiency: the number of times N that steps 1 and 2 need to be called(also the number of iterations needed to successfully generate X) is a random variable and has a geometric distribution with success probability p=P(U<= f(Y)/(cg(Y),P(N=n))=(1p^(n1)*p,n>=1.Thus on average the number of iterations required is given by E(N)=1/p
c should be close to the maximum of f(x)/g(x), not just some arbitrarily picked large number. Otherwise, the AcceptanceRejection method will have more rejections (since our probability [math]f(x)\leqslant c g(x)[/math] will be close to zero). This will render our algorithm inefficient.
The expected number of iterations of the algorithm required with an X is c.
Note:
1. Value around x_{1} will be sampled more often under cg(x) than under f(x).There will be more samples than we actually need, if [math]\frac{f(y)}{\, c g(y)}[/math] is small, the acceptancerejection technique will need to be done to these points to get the accurate amount.In the region above x_{1}, we should accept less and reject more.
2. Value around x_{2}: number of sample that are drawn and the number we need are much closer. So in the region above x_{2}, we accept more. As a result, g(x) and f(x) are comparable.
3. The constant c is needed because we need to adjust the height of g(x) to ensure that it is above f(x). Besides that, it is best to keep the number of rejected varieties small for maximum efficiency.
Another way to understand why the the acceptance probability is [math]\frac{f(y)}{\, c g(y)}[/math], is by thinking of areas. From the graph above, we see that the target function in under the proposed function c g(y). Therefore, [math]\frac{f(y)}{\, c g(y)}[/math] is the proportion or the area under c g(y) that also contains f(y). Therefore we say we accept sample points for which u is less then [math]\frac{f(y)}{\, c g(y)}[/math] because then the sample points are guaranteed to fall under the area of c g(y) that contains f(y).
There are 2 cases that are possible:
Sample of points is more than enough, [math]c g(x) \geq f(x) [/math]
Similar or the same amount of points, [math]c g(x) \geq f(x) [/math]
There is 1 case that is not possible:
Less than enough points, such that [math] g(x) [/math] is greater than [math] f [/math], [math]g(x) \geq f(x)[/math]
Procedure
Note: Recall [math]P(U\leq a)=a[/math]. Thus by comparing u and [math]\frac{f(y)}{\, c g(y)}[/math], we can get a probability of accepting y at these points. For instance, at some points that cg(x) is much larger than f(x), the probability of accepting x=y is quite small.
ie. At X_{1}, low probability to accept the point since f(x) much smaller than cg(x).
At X_{2}, high probability to accept the point. [math]P(U\leq a)=a[/math] in Uniform Distribution.
Note: Since U is the variable for uniform distribution between 0 and 1. It equals to 1 for all. The condition depends on the constant c. so the condition changes to [math]c\leq \frac{f(y)}{g(y)}[/math]
introduce the relationship of cg(x)and f(x),and prove why they have that relationship and where we can use this rule to reject some cases.
and learn how to see the graph to find the accurate point to reject or accept the ragion above the random variable x.
for the example, x1 is bad point and x2 is good point to estimate the rejection and acceptance
Theorem
Let [math]f: \R \rightarrow [0,+\infty][/math] be a welldefined pdf, and [math]\displaystyle Y[/math] be a random variable with pdf [math]g: \R \rightarrow [0,+\infty][/math] such that [math]\exists c \in \R^+[/math] with [math]f \leq c \cdot g[/math]. If [math]\displaystyle U \sim~ U(0,1)[/math] is independent of [math]\displaystyle Y[/math], then the random variable defined as [math]X := Y \vert U \leq \frac{f(Y)}{c \cdot g(Y)}[/math] has pdf [math]\displaystyle f[/math], and the condition [math]U \leq \frac{f(Y)}{c \cdot g(Y)}[/math] is denoted by "Accepted".
Proof
(to be updated later)
[math]P(yaccepted)=f(y)[/math]
[math]P(yaccepted)=\frac{P(acceptedy)P(y)}{P(accepted)}[/math]
Recall the conditional probability formulas:
[math]\begin{align}
P(AB)=\frac{P(A \cap B)}{P(B)}, \text{ or }P(AB)=\frac{P(BA)P(A)}{P(B)} \text{ for pmf}
\end{align}[/math]
based on the concept from procedurestep1:
[math]P(y)=g(y)[/math]
[math]P(acceptedy)=\frac{f(y)}{cg(y)}[/math]
(the larger the value is, the larger the chance it will be selected)
[math]
\begin{align}
P(accepted)&=\int_y\ P(acceptedy)P(y)\\
&=\int_y\ \frac{f(s)}{cg(s)}g(s)ds\\
&=\frac{1}{c} \int_y\ f(s) ds\\
&=\frac{1}{c}
\end{align}[/math]
Therefore:
[math]\begin{align}
P(x)&=P(yaccepted)\\
&=\frac{\frac{f(y)}{cg(y)}g(y)}{1/c}\\
&=\frac{\frac{f(y)}{c}}{1/c}\\
&=f(y)\end{align}[/math]
Here is an alternative introduction of AcceptanceRejection Method
Comments:
AcceptanceRejection Method is not good for all cases. One obvious cons is that it could be very hard to pick the g(y) and the constant c in some cases. And usually, c should be a small number otherwise the amount of work when applying the method could be HUGE.
Note: When f(y) is very different than g(y), it is less likely that the point will be accepted as the ratio above would be very small and it will be difficult for u to be less than this small value.
An example would be when the target function (f) has a spike or several spikes in its domain  this would force the known distribution (g) to have density at least as large as the spikes, making the value of c larger than desired. As a result, the algorithm would be highly inefficient.
AcceptanceRejection Method
Example 1 (discrete case)
We wish to generate X~Bi(2,0.5), assuming that we cannot generate this directly.
We use a discrete distribution DU[0,2] to approximate this.
[math]f(x)=Pr(X=x)=2Cx*(0.5)^2[/math]
x  0  1  2
f(x)  1/4  1/2  1/4
g(x)  1/3  1/3  1/3
c=f(x)/g(x)  3/4  3/2  3/4
f(x)/(cg(x))  1/2  1  1/2
Since we need [math]c\gt =f(x)/g(x)[/math]
We need [math]c=3/2[/math]
Therefore, the algorithm is:
1. Generate [math]u,v~U(0,1)[/math]
2. Set [math]y= \lfloor 3*u \rfloor[/math] (This is using uniform distribution to generate DU[0,2]
3. If [math](y=0)[/math] and [math](v\lt 1/2), output=0[/math]
If [math](y=2) [/math] and [math](v\lt 1/2), output=2 [/math]
Else if [math]y=1, output=1[/math]
An elaboration of “c”
c is the expected number of times the code runs to output 1 random variable. Remember that when [math]u \lt f(x)/(cg(x))[/math] is not satisfied, we need to go over the code again.
Proof
Let [math]f(x)[/math] be the function we wish to generate from, but we cannot use inverse transform method to generate directly.
Let [math]g(x)[/math] be the helper function
Let [math]kg(x)\gt =f(x)[/math]
Since we need to generate y from [math]g(x)[/math],
[math]Pr(select y)=g(y)[/math]
[math]Pr(output yselected y)=Pr(u\lt f(y)/(cg(y)))= (y)/(cg(y))[/math] (Since u~Unif(0,1))
[math]Pr(output y)=Pr(output y1selected y1)Pr(select y1)+ Pr(output y2selected y2)Pr(select y2)+…+ Pr(output ynselected yn)Pr(select yn)=1/c[/math]
Consider that we are asking for expected time for the first success, it is a geometric distribution with probability of success=c
Therefore, [math]E(X)=1/(1/c))=c[/math]
Acknowledgements: Some materials have been borrowed from notes from Stat340 in Winter 2013.
Use the conditional probability to proof if the probability is accepted, then the result is closed pdf of the original one. the example shows how to choose the c for the two function g(x) and f(x).
Example of AcceptanceRejection Method
Generating a random variable having p.d.f.
[math]f(x) = 20x(1  x)^3, 0\lt x \lt 1 [/math]
Since this random variable (which is beta with parameters 2, 4) is concentrated in the interval (0, 1), let us consider the acceptancerejection method with
g(x) = 1, 0 < x < 1
To determine the constant c such that f(x)/g(x) <= c, we use calculus to determine the maximum value of
[math] f(x)/g(x) = 20x(1  x)^3 [/math]
Differentiation of this quantity yields
[math]d/dx[f(x)/g(x)]=20*[(1x)^33x(1x)^2][/math]
Setting this equal to 0 shows that the maximal value is attained when x = 1/4, and thus,
[math]f(x)/g(x)\lt = 20*(1/4)*(3/4)^3=135/64=c [/math]
Hence,
[math]f(x)/cg(x)=(256/27)*(x*(1x)^3)[/math]
and thus the simulation procedure is as follows:
1) Generate two random numbers U1 and U2 .
2) If U_{2}<(256/27)*U_{1}*(1U_{1})^{3}, set X=U_{2}, and stop Otherwise return to step 1). The average number of times that step 1) will be performed is c = 135/64.
(The above example is from http://www.cs.bgu.ac.il/~mps042/acceptance.htm, example 2.)
use the derivative to proof the accepetancerejection method, find the local maximum of f(x)/g(x). and we can calculate the best constant c.
Simple Example of AcceptanceRejection Method
Consider the random variable X, with distribution [math] X [/math] ~ [math] U[0,0.5] [/math]
So we let [math] f(x) = 2x [/math] on [math] [0, 1/2] [/math]
Let [math]g(.)[/math] be [math]U[0,1][/math] distributed. So [math]g(x) = x[/math] on [math][0,1][/math]
Then take [math]c = 2[/math]
So [math]f(x)/cg(x) = (2x) / {(2)(x) } = 1[/math] on the interval [math][0, 1/2][/math] and
[math]f(x)/cg(x) = (0) / {(2)(x) } = 0[/math] on the interval [math](1/2, 1][/math]
So we reject:
None of the numbers generated in the interval [math][0, 1/2][/math]
All of the numbers generated in the interval [math](1/2, 1][/math]
And this results in the distribution [math]f(.)[/math] which is [math]U[0,1/2][/math]
a example to show why the we reject a case by using acceptancerejection method.
Another Example of AcceptanceRejection Method
Generate a random variable from:
[math]f(x)=3*x^2[/math], 0< x <1
Assume g(x) to be uniform over interval (0,1), where 0< x <1
Therefore:
[math]c = max(f(x)/(g(x)))= 3[/math]
the best constant c is the max(f(x)/(cg(x))) and the c make the area above the f(x) and below the g(x) to be small. because g(.) is uniform so the g(x) is 1. max(g(x)) is 1
[math]f(x)/(cg(x))= x^2[/math]
Acknowledgement: this is example 1 from http://www.cs.bgu.ac.il/~mps042/acceptance.htm
an example to show how to figure out c and f(x)/c*g(x).
Class 4  Thursday, May 16
How to find C:
[math]\begin{align}
&c \cdot g(x) \geq f(x)\\
&c\geq \frac{f(x)}{g(x)} \\
&c= \max \left(\frac{f(x)}{g(x)}\right)
\end{align}[/math]
If [math]f[/math] and [math] g [/math] are continuous, we can find the extremum by taking the derivative and solve for [math]x_0[/math] such that:
[math] 0=\frac{d}{dx}\frac{f(x)}{g(x)}_{x=x_0}[/math]
Thus [math] c = \frac{f(x_0)}{g(x_0)} [/math]
The AcceptanceRejection method involves finding a distribution that we know how to sample from (g(x)) and multiplying g(x) by a constant c so that [math]c \cdot g(x)[/math] is always greater than or equal to f(x). Mathematically, we want [math] c \cdot g(x) \geq f(x) [/math].
And it means c has to be greater or equal to [math]\frac{f(x)}{g(x)}[/math]. So the smallest possible c that satisfies the condition is the maximum value of [math]\frac{f(x)}{g(x)}[/math]
. If c is made to be too large, the chance of acceptance of generated values will be small, and the algorithm will lose its purpose since the acceptance will be very small. Therefore, it is best to get the smallest posisble c such that [math] c g(x) \geq f(x)[/math].
Procedure:
1. Choose [math]g(x)[/math] (simple density function that we know how to sample, i.e. Uniform so far)
The easiest case is UNIF(0,1). However, in other cases we need to generate UNIF(a,b). We may need to perform a linear transformation on the UNIF(0,1) variable.
2. Find a constant c such that :[math] c \cdot g(x) \geq f(x) [/math], otherwise return to step 1.
Recall the general procedure of AcceptanceRejection Method
Example: Generate a random variable from the pdf
[math] f(x) = \begin{cases} 2x, & \mbox{if }0 \leqslant x \leqslant 1 \\ 0, & \mbox{otherwise} \end{cases} [/math]
We can note that this is a special case of Beta(2,1), where,
[math]beta(a,b)=\frac{\Gamma(a+b)}{\Gamma(a)\Gamma(b)}x^{(a1)}(1x)^{(b1)}[/math]
Where Γ (n)=(n1)! if n is positive integer
[math]Gamma(z)=\int _{0}^{\infty }t^{z1}e^{t}dt[/math]
Aside: Beta function
In mathematics, the beta function, also called the Euler integral of the first kind, is a special function defined by
[math]B(x,y)=\int_0^1 \! {t^{(x1)}}{(1t)^{(y1)}}\,dt[/math]
[math]beta(2,1)= \frac{\Gamma(3)}{(\Gamma(2)\Gamma(1))}x^1 (1x)^0 = 2x[/math]
[math]g=u(0,1)[/math]
[math]y=g[/math]
[math]f(x)\leq c\cdot g(x)[/math]
[math]c\geq \frac{f(x)}{g(x)}[/math]
[math]c = \max \frac{f(x)}{g(x)} [/math]
[math]c = \max \frac{2x}{1}, 0 \leq x \leq 1[/math]
Taking x = 1 gives the highest possible c, which is c=2
Note that c is a scalar greater than 1.
Note: g follows uniform distribution, it only covers half of the graph which runs from 0 to 1 on yaxis. Thus we need to multiply by c to ensure that [math]c\cdot g[/math] can cover entire f(x) area. In this case, c=2, so that makes g runs from 0 to 2 on yaxis which covers f(x).
Comment:
From the picture above, we could observe that the area under f(x)=2x is a half of the area under the pdf of UNIF(0,1). This is why in order to sample 1000 points of f(x) we need to sample approximately 2000 points in UNIF(0,1).
And in general, if we want to sample n points from a distritubion with pdf f(x), we need to scan approximately [math]n\cdot c[/math] points from the proposal distribution (g(x)) in total.
Step
Note: In the above example, we sample 2 numbers. If second number is equal to first one then accept, if not then start all over.
Matlab Code
>>close all >>clear all >>ii=1; # ii:numbers that are accepted >>jj=1; # jj:numbers that are generated >>while ii<1000 y=rand; u=rand; jj=jj+1; if u<=y x(ii)=y; ii=ii+1; end end >>hist(x) >>jj jj = 2024 # should be around 2000
Example for AR method:'
Given [math] f(x)= \frac{3}{4} (1x^2), 1 \leq x \leq 1 [/math], use AR method to generate random number
Let g=U(1,1) and g(x)=1/2
let y ~ f, [math] cg(x)\geq f(x), c\frac{1}{2} \geq \frac{3}{4} (1x^2) /1, c=max 2*\frac{3}{4} (1x^2) = 3/2 [/math]
The process:
Use Inverse Method for this Example
Matlab Code
>>u=rand(1,1000); >>x=u.^0.5; >>hist(x)
Matlab Tip: Periods, ".",meaning "elementwise", are used to describe the operation you want performed on each element of a vector. In the above example, to take the square root of every element in U, the notation U.^0.5 is used. However if you want to take the Square root of the entire matrix U the period, "*.*" would be excluded. i.e. Let matrix B=U^0.5, then [math]B^T*B=U[/math]. For example if we have a two 1 X 3 matrices and we want to find out their product; using "." in the code will give us their product; however, if we don't use "." it will just give us an error. For example, a =[1 2 3] b=[2 3 4] are vectors, a.*b=[2 6 12], but a*b does not work since matrix dimensions must agree.
Example of AcceptanceRejection Method
[math] f(x) = 3x^2, 0\lt x\lt 1 [/math] [math]g(x)=1, 0\lt x\lt 1[/math]
[math]c = \max \frac{f(x)}{g(x)} = \max \frac{3x^2}{1} = 3 [/math]
[math]\frac{f(x)}{c \cdot g(x)} = x^2[/math]
1. Generate two uniform numbers in the unit interval [math]U_1, U_2 \sim~ U(0,1)[/math]
2. If [math]U_2 \leqslant {U_1}^2[/math], accept [math]U_1[/math] as the random variable with pdf [math]f[/math], if not return to Step 1
We can also use [math]g(x)=2x[/math] for a more efficient algorithm
[math]c = \max \frac{f(x)}{g(x)} = \max \frac {3x^2}{2x} = \frac {3x}{2} [/math]. Use the inverse method to sample from [math]g(x)[/math] [math]G(x)=x^2[/math]. Generate [math]U[/math] from [math]U(0,1)[/math] and set [math]x=sqrt(u)[/math]
1. Generate two uniform numbers in the unit interval [math]U_1, U_2 \sim~ U(0,1)[/math]
2. If [math]U_2 \leq \frac{3\sqrt{U_1}}{2}[/math], accept [math]U_1[/math] as the random variable with pdf [math]f[/math], if not return to Step 1
Possible Limitations
This method could be computationally inefficient depending on the rejection rate. We may have to sample many points before
we get the 1000 accepted points. In the example we did in class relating the [math]f(x)=2x[/math],
we had to sample around 2070 points before we finally accepted 1000 sample points.
If the form of the proposal distribution, g, is very different from target distribution, f, then c is very large and the algorithm is not computationally efficient.
Acceptance  Rejection Method Application on Normal Distribution
[math]X \sim∼ N(\mu,\sigma^2), \text{ or } X = \sigma Z + \mu, Z \sim~ N(0,1) [/math]
[math]\vert Z \vert[/math] has probability density function of
f(x) = (2/[math]\sqrt{2\pi}[/math]) e^{x2/2}
g(x) = e^{x}
Take h(x) = f(x)/g(x) and solve for h'(x) = 0 to find x so that h(x) is maximum.
Hence x=1 maximizes h(x) => c = [math]\sqrt{2e/\pi}[/math]
Thus f(y)/cg(y) = e^{(y1)2/2}
learn how to use code to calculate the c between f(x) and g(x).
How to transform [math]U(0,1)[/math] to [math]U(a, b)[/math]
1. Draw U from [math]U(0,1)[/math]
2. Take [math]Y=(ba)U+a[/math]
3. Now Y follows [math]U(a,b)[/math]
Example: Generate a random variable z from the Semicircular density [math]f(x)= \frac{2}{\pi R^2} \sqrt{R^2x^2}, R\leq x\leq R[/math].
> Proposal distribution: UNIF(R, R)
> We know how to generate using [math] U \sim UNIF (0,1) [/math] Let [math] Y= 2RUR=R(2U1)[/math], therefore Y follows [math]U(a,b)[/math]
> In order to maximize the function we must maximize the top and minimize the bottom.
Now, we need to find c:
Since c=max[f(x)/g(x)], where
[math]f(x)= \frac{2}{\pi R^2} \sqrt{R^2x^2}[/math], [math]g(x)=\frac{1}{2R}[/math], [math]R\leq x\leq R[/math]
Thus, we have to maximize R^2x^2.
=> When x=0, it will be maximized.
Therefore, c=4/pi. * Note: This also means that the probability of accepting a point is pi/4.
We will accept the points with limit f(x)/[cg(x)]. Since [math]\frac{f(y)}{cg(y)}=\frac{\frac{2}{\pi R^{2}} \sqrt{R^{2}y^{2}}}{\frac{4}{\pi} \frac{1}{2R}}=\frac{\frac{2}{\pi R^{2}} \sqrt{R^{2}R^{2}(2U1)^{2}}}{\frac{2}{\pi R}}[/math]
We can also get Y= R(2U1) by using the formula y = a+(ba)*u, to transform U~(0,1) to U~(a,b). Letting a=R and b=R, and substituting it in the formula y = a+(ba)*u, we get Y= R(2U1).
Thus, [math]\frac{f(y)}{cg(y)}=\sqrt{1(2U1)^{2}}[/math] * this also means the probability we can accept points
1. Draw [math]\ U[/math] from [math]\ U(0,1)[/math]
2. Draw [math]\ U_{1}[/math] from [math]\ U(0,1)[/math]
3. If [math]U_{1} \leq \sqrt{1(2U1)^2}, x = y [/math]
else return to step 1.
The condition is
[math] U_{1} \leq \sqrt{(1(2U1)^2)}[/math]
[math]\ U_{1}^2 \leq 1  (2U 1)^2[/math]
[math]\ U_{1}^2  1 \leq (2U  1)^2[/math]
[math]\ 1  U_{1}^2 \geq (2U  1)^2[/math]
One more example about AR method
(In this example, we will see how to determine the value of c when c is a function with unknown parameters instead of a value)
Let [math]f(x)=x*e^{x}, x\gt 0 [/math]
Use [math]g(x)=a*e^{a*x}[/math]to generate random variable
Solution: First of all, we need to find c
[math]cg(x)\gt =f(x)[/math]
[math]c\gt =\frac{f(x)}{g(x)}[/math]
[math]\frac{f(x)}{g(x)}=\frac{x}{a} * e^{(1a)x}[/math]
take derivative with respect to x, and set it to 0 to get the maximum,
[math]\frac{1}{a} * e^{(1a)x}  \frac{x}{a} * e^{(1a)x} * (1a) = 0 [/math]
[math]x=\frac {1}{1a}[/math]
[math]\frac {f(x)}{g(x)} = \frac {e^{1}}{a*(1a)} [/math]
[math]\frac {f(0)}{g(0)} = 0[/math]
[math]\frac {f(infinity)}{g(infinity)} = 0[/math]
therefore, [math]c= \frac {e^{1}}{a*(1a)}[/math]
In order to minimize c, we need to find the appropriate a
Take derivative with respect to a and set it to be zero,
We could get [math]a= \frac {1}{2}[/math]
[math]c=\frac{4}{e}[/math]
Procedure:
1. Generate u v ~unif(0,1)
2. Generate y from g, since g is exponential with rate 2, let y=ln(u)
3. If [math]v\lt \frac{f(y)}{c\cdot g(y)}[/math], output y
Else, go to 1
Acknowledgements: The example above is from Stat 340 Winter 2013 notes.
Summary of how to find the value of c
Let [math]h(x) = \frac {f(x)}{g(x)}[/math], and then we have the following:
1. First, take derivative of h(x) with respect to x, get x_{1};
2. Plug x_{1} into h(x) and get the value(or a function) of c, denote as c_{1};
3. Check the endpoints of x and sub the endpoints into h(x);
4. (if c_{1} is a value, then we can ignore this step) Since we want the smallest value of c such that [math]f(x) \leq c\cdot g(x)[/math] for all x, we want the unknown parameter that minimizes c.
So we take derivative of c_{1} with respect to the unknown parameter (ie k=unknown parameter) to get the value of k.
Then we submit k to get the value of c_{1}. (Double check that [math]c_1 \geq 1[/math]
5. Pick the maximum value of h(x) to be the value of c.
For the two examples above, we need to generate the probability function to uniform distribution, and figure out [math]c=max\frac {f(y)}{g(y)} [/math]. If [math]v\lt \frac {f(y)}{c\cdot g(y)}[/math], output y.
Summary of when to use the Accept Rejection Method
1) When the calculation of inverse cdf cannot to be computed or too difficult to compute.
2) When f(x) can be evaluated to at least one of the normalizing constant.
3) A constant c where [math]f(x)\leq c\cdot g(x)[/math]
4) A uniform draw
Interpretation of 'C'
We can use the value of c to calculate the acceptance rate by '1/c'.
For instance, assume c=1.5, then we can tell that 66.7% of the points will be accepted (1/1.5=0.667).
Class 5  Tuesday, May 21
Recall the example in the last lecture. The following code will generate a random variable required by the question in that question.
>>close all >>clear all >>ii=1; >>R=1; #Note: that R is a constant in which we can change i.e. if we changed R=4 then we would have a density between 4 and 4 >>while ii<1000 u1 = rand; u2 = rand; y = R*(2*u21); if (1u1^2)>=(2*u21)^2 x(ii) = y; ii = ii + 1; #Note: for beginner programers that this step increases the ii value for next time through the while loop end end >>hist(x,20)
MATLAB tips: hist(x,y) where y is the number of bars in the graph.
a histogram to show variable x, and the bars number is y.
Discrete Examples
Generate random variable [math]X[/math] according to p.m.f
[math]\begin{align}
P(x &=1) &&=0.15 \\
P(x &=2) &&=0.25 \\
P(x &=3) &&=0.3 \\
P(x &=4) &&=0.1 \\
P(x &=5) &&=0.2 \\
\end{align}[/math]
The discrete case is analogous to the continuous case. Suppose we want to generate an X that is a discrete random variable with pmf f(x)=P(X=x). Suppose we can already easily generate a discrete random variable Y with pmf g(x)=P(Y=x)such that sup_{x} {f(x)/g(x)}<= c < ∞. The following algorithm yields our X:
Step 1. Draw discrete uniform distribution of 1, 2, 3, 4 and 5, [math]Y \sim~ g[/math].
Step 2. Draw [math]U \sim~ U(0,1)[/math].
Step 3. If [math]U \leq \frac{f(Y)}{c \cdot g(Y)}[/math], then X = Y ;
Else return to Step 1.
How do we compute c? Recall that c can be found by maximizing the ratio :[math] \frac{f(x)}{g(x)} [/math]. Note that this is different from maximizing [math] f(x) [/math] and [math] g(x) [/math] independently of each other and then taking the ratio to find c.
Note: The U is independent from y in Step 2 and 3 above. ~The constant c is a indicator of rejection rate
the acceptancerejection method of pmf, the uniform pro is the same for all variables, and there 5 parameters(1,2,3,4,5), so g(x) is 0.2
Remember that we always want to choose [math] cg [/math] to be equal to or greater than [math] f [/math], but as close as possible.
>>close all >>clear all >>p=[.15 .25 .3 .1 .2]; #This a vector holding the values >>ii=1; >>while ii < 1000 y=unidrnd(5); u=rand; if u<= p(y)/0.3 x(ii)=y; ii=ii+1; end end >>hist(x)
unidrnd(k) draws from the discrete uniform distribution of integers [math]1,2,3,...,k[/math] If this function is not built in to your MATLAB then we can do simple transformation on the rand(k) function to make it work like the unidrnd(k) function.
The acceptance rate is [math]\frac {1}{c}[/math], so the lower the c, the more efficient the algorithm. Theoretically, c equals 1 is the best case because all samples would be accepted; however it would only be true when the proposal and target distributions are exactly the same, which would never happen in practice.
For example, if c = 1.5, the acceptance rate would be [math]\frac {1}{1.5}=\frac {2}{3}[/math]. Thus, in order to generate 1000 random values, a total of 1500 iterations would be required.
A histogram to show 1000 random values of f(x), more random value make the probability close to the express probability value.
p(x=1)=0.1
p(x=2)=0.3
p(x=3)=0.6
Let g be the uniform distribution of 1, 2, or 3
g(x)= 1/3
[math]c=max(p_{x}/g(x))=0.6/(1/3)=1.8[/math]
1,y~g
2,u~U(0,1)
3, If [math]U \leq \frac{f(y)}{cg(y)}[/math], set x = y. Else go to 1.
>>close all >>clear all >>p=[.1 .3 .6]; >>ii=1; >>while ii < 1000 y=unidrnd(3); u=rand; if u<= p(y)/1.8 x(ii)=y; ii=ii+1; end end >>hist(x)
[math]p_{x}=e^{3}3^{x}/x! , x\gt =0[/math]
(poisson distribution)
Try the first few p_{x}'s: .0498 .149 .224 .224 .168 .101 .0504 .0216 .0081 .0027
Use the geometric distribution for [math]g(x)[/math];
[math]g(x)=p(1p)^{x}[/math], choose p=0.25
Look at [math]p_{x}/g(x)[/math] for the first few numbers: .199 .797 1.59 2.12 2.12 1.70 1.13 .647 .324 .144
We want [math]c=max(p_{x}/g(x))[/math] which is approximately 2.12
1. Generate [math]U_{1} \sim~ U(0,1); U_{2} \sim~ U(0,1)[/math]
2. [math]j = \lfloor \frac{ln(U_{1})}{ln(.75)} \rfloor;[/math]
3. if [math]U_{2} \lt \frac{p_{j}}{cg(j)}[/math], set X = x_{j}, else go to step 1.
Suppose we are given f(x) such that it is hypergeometically distributed, given 10 white balls, 5 red balls, and select 3 balls, let X be the number of red ball selected, without replacement.
Choose g(x) such that it is binomial distribution, Bin(3, 1/3). Find the rejection constant, c
Solution:
For hypergeometric: [math]P(X=0) =\binom{10}{3}/\binom{15}{3} =0.2637, P(x=1)=\binom{10}{2} * \binom{5}{1} /\binom{15}{3}=0.4945, P(X=2)=\binom{10}{1} * \binom{5}{2} /\binom{15}{3}=0.2198,[/math]
[math]P(X=3)=\binom{5}{3}/\binom{15}{3}= 0.02198[/math]
For Binomial g(x): P(X=0) = (2/3)^3=0.2963; P(X=1)= 3*(1/3)*(2/3)^2 = 0.4444, P(X=2)=3*(1/3)^2*(2/3)=0.2222, P(X=3)=(1/3)^3=0.03704
Find the value of f/g for each X
X=0: 0.8898; X=1: 1.1127; X=2: 0.9891; X=3: 0.5934
Choose the maximum which is c=1.1127
Looking for the max f(x) is 0.4945 and the max g(x) is 0.4444, so we can calculate the max c is 1.1127. But for the graph, this c is not the best because it does not cover all the point of f(x), so we need to move the c*g(x) graph to cover all f(x), and decreasing the rejection ratio.
Limitation: If the shape of the proposed distribution g is very different from the target distribution f, then the rejection rate will be high (High c value). Computationally, the algorithm is always right; however it is inefficient and requires many iterations.
Here is an example:
In the above example, we need to move c*g(x) to the peak of f to cover the whole f. Thus c will be very large and 1/c will be small.
The higher the rejection rate, more points will be rejected.
More on rejection/acceptance rate: 1/c is the acceptance rate. As c decreases (note: the minimum value of c is 1), the acceptance rate increases. In our last example, 1/c=1/1.5≈66.67%. Around 67% of points generated will be accepted.
which brings the acceptance rate low which leads to very time take sampling
AcceptanceRejection Method
Problem: The CDF is not invertible or it is difficult to find the inverse.
Plan:
x will have the desired distribution.
Matlab Example
close all clear all ii=1; R=1; while ii<1000 u1 = rand; u2 = rand; y = R*(2*u21); if (1u1^2)>=(2*u21)^2 x(ii) = y; ii = ii + 1; end end hist(x,20)
Recall that,
Suppose we have an efficient method for simulating a random variable having probability mass function {q(j),j>=0}. We can use this as the basis for simulating from the distribution having mass function {p(j),j>=0} by first simulating a random variable Y having mass function {q(j)} and then accepting this simulated value with a probability proportional to p(Y)/q(Y).
Specifically, let c be a constant such that p(j)/q(j)<=c for all j such that p(j)>0
We now have the following technique, called the acceptancerejection method, for simulating a random variable X having mass function p(j)=P{X=j}.
Sampling from commonly used distributions
Please note that this is not a general technique as is that of acceptancerejection sampling. Later, we will generalize the distributions for multidimensional purposes.
The CDF of the Gamma distribution [math]Gamma(t,\lambda)[/math] is:
[math] F(x) = \int_0^{\lambda x} \frac{e^{y}y^{t1}}{(t1)!} \mathrm{d}y, \; \forall x \in (0,+\infty)[/math], where [math]t \in \N^+ \text{ and } \lambda \in (0,+\infty)[/math].
Neither Inverse Transformation nor Acceptance/Rejection Method can be easily applied to Gamma distribution.
However, we can use additive property of Gamma distribution to generate random variables.
If [math]X_1, \dots, X_t[/math] are independent exponential distributions with hazard rate [math] \lambda [/math] (in other words, [math] X_i\sim~ Exp (\lambda) [/math][math] Exp (\lambda)= Gamma (1, \lambda)), then \Sigma_{i=1}^t X_i \sim~ Gamma (t, \lambda) [/math]
Side notes: if [math] X_i\sim~ Gamma(a,\lambda)[/math] and [math] Y_i\sim~ Gamma(B,\lambda)[/math] are independent gamma distributions, then [math]\frac{X}{X+Y}[/math] has a distribution of [math] Beta(a,B).
If we want to sample from the Gamma distribution, we can consider sampling from \lt math\gt t[/math] independent exponential distributions using the Inverse Method for each [math] X_i[/math] and add them up.
According to this property, a random variable that follows Gamma distribution is the sum of i.i.d (independent and identically distributed) exponential random variables. Now we want to generate 1000 values of [math]Gamma(20,10)[/math] random variables, so we need to obtain the value of each one by adding 20 values of [math]X_i \sim~ Exp(10)[/math]. To achieve this, we generate a 20by1000 matrix whose entries follow [math]Exp(10)[/math] and add the rows together. [math] x_1 [/math]~Exp([math]\lambda [/math]) [math]x_2 [/math]~Exp([math] \lambda [/math]) ... [math]x_t [/math]~Exp([math] \lambda [/math]) [math]x_1+x_2+...+x_t[/math]
>>l=1 >>urand(1,1000); >>x=(1/l)*log(u); >>hist(x) >>rand
>>close all >>clear all >>lambda = 1; >>u = rand(20, 1000); Note: this command generate a 20x1000 matrix (which means we generate 1000 number for each X_i with t=20); all the elements are generated by rand >>x = (1/lambda)*log(1u); Note: log(1u) is essentially the same as log(u) only if u~U(0,1) >>xx = sum(x) Note: sum(x) will sum all elements in the same column. size(xx) can help you to verify >>size(sum(x)) Note: see the size of x if we forget it (the answer is 20 1000) >>hist(x(1:)) Note: the graph of the first exponential distribution >>hist(xx)
size(x) and size(u) are both 20*1000 matrix. Since if u~unif(0, 1), u and 1  u have the same distribution, we can substitue 1u with u to simply the equation. Alternatively, the following command will do the same thing with the previous commands.
>>close all >>clear all >>lambda = 1; >>xx = sum((1/lambda)*log(rand(20, 1000))); ''This is simple way to put the code in one line. Here we can use either log(u) or log(1u) since U~U(0,1); >>hist(xx)
in the matrix rand(20,1000) means 20 row with 1000 numbers for each. use the code to show the generalize the distributions for multidimensional purposes in different cases, such as sum xi (each xi not equal xj), and they are independent, or matrix. Finally, we can see the conclusion is shown by the histogram.
Other Sampling Method: Coordinate System
[math] R=\sqrt{x_{1}^2+x_{2}^2}= x_{2}/sin(\theta)= x_{1}/cos(\theta)[/math]
[math] tan(\theta)=x_{2}/x_{1} \rightarrow \theta=tan^{1}(x_{2}/x_{1})[/math]
if the graph is straight line, we can set the length of the line is R, and x=cos(sigma) , y=sin(sigma)
Matlab
If X is a matrix;
Class 6  Thursday, May 23
Announcement
1. On the day of each lecture, students from the morning section can only contribute the first half of the lecture (i.e. 8:30  9:10 am), so that the second half can be saved for the ones from the afternoon section. After the day of lecture, students are free to contribute anything.
Standard Normal distribution
If X ~ N(0,1) i.e. Standard Normal Distribution  then its p.d.f. is of the form
[math] f(x) = \frac{1}{\sigma\sqrt{2\pi}} e^{ \frac{(x\mu)^2}{2\sigma^2} } [/math]
which is almost useless in this course

where [math] \mu [/math] is the mean or expectation of the distribution and [math] \sigma [/math] is standard deviation
Let X and Y be independent standard normal.
Let [math] \theta [/math] and R denote the Polar coordinate of the vector (X, Y)
Note: R must satisfy two properties:
The form of the joint distribution of R and [math]\theta[/math] will show that the best choice for distribution of R^{2} is exponential.
We cannot use the Inverse Transformation Method since F(x) does not have a closed form solution. So we will use joint probability function of two independent standard normal random variables and polar coordinates to simulate the distribution:
We know that
It can also be shown using 11 transformation that the joint distribution of R and θ is given by,
11 transformation:
Let [math]d=R^2[/math]
[math]x= \sqrt {d}\cos \theta [/math] [math]y= \sqrt {d}\sin \theta [/math]
then [math]\left J\right = \left \dfrac {1} {2}d^{\frac {1} {2}}\cos \theta d^{\frac{1}{2}}\cos \theta +\sqrt {d}\sin \theta \dfrac {1} {2}d^{\frac{1}{2}}\sin \theta \right = \dfrac {1} {2}[/math] It can be shown that the pdf of [math] d [/math] and [math] \theta [/math] is:
Note that [math] \begin{matrix}f(r,\theta)\end{matrix}[/math] consists of two density functions, Exponential and Uniform, so assuming that r and [math]\theta[/math] are independent [math] \begin{matrix} \Rightarrow d \sim~ Exp(1/2), \theta \sim~ Unif[0,2\pi] \end{matrix} [/math]
[math]\begin{align} f(d) = Exp(1/2)=\frac{1}{2}e^{\frac{d}{2}}\ \end{align}[/math]
[math]\begin{align} f(\theta) =\frac{1}{2\pi}\ \end{align}[/math]
To sample from the normal distribution, we can generate a pair of independent standard normal X and Y by:
1) Generating their polar coordinates
2) Transforming back to rectangular (Cartesian) coordinates.
Expectation of a Standard Normal distribution
The expectation of a standard normal distribution is 0
More intuitively, because x is an odd function (f(x)+f(x)=0). Taking integral of x will give [math]x^2/2 [/math] which is an even function (f(x)=f(x)). If support is from negative infinity to infinity, then the integral will return 0.
Pseudorandom approaches to generating normal random variables used to be limited. Inefficient methods such as inverse Gaussian function, sum of uniform random variables, and acceptancerejection were used. In 1958, a new method was proposed by George Box and Mervin Muller of Princeton University. This new technique had the easy of use and accuracy to the inverse transform sampling method that grew more valuable as computers became more computationally astute since then.
The BoxMuller method takes a sample from a bivariate independent standard normal distribution, each component of which is thus a univariate standard normal. The algorithm is based on the following two properties of the bivariate independent standard normal distribution:
if Z = (Z_{1}, Z_{2}) has this distribution, then
1.R^{2}=Z_{1}^{2}+Z_{2}^{2} is exponentially distributed with mean 2, i.e.
P(R^{2} <= x) = 1e^{x/2}.
2.GivenR^{2}, the point (Z_{1},Z_{2}) is uniformly distributed on the circle of radius R centered at the origin.
We can use these properties to build the algorithm:
1) Generate random number [math] \begin{align} U_1,U_2 \sim~ \mathrm{Unif}(0, 1) \end{align} [/math]
2) Generate polar coordinates using the exponential distribution of d and uniform distribution of θ,
[math] \begin{align} R^2 = d = 2\log(U_1), & \quad r = \sqrt{d} \\ & \quad \theta = 2\pi U_2 \end{align} [/math]
[math] \begin{matrix} \ R^2 \sim~ Exp(2), \theta \sim~ Unif[0,2\pi] \end{matrix} [/math]
Note: If U~unif(0,1), then ln(1U)=ln(U)
3) Transform polar coordinates (i.e. R and θ) back to Cartesian coordinates (i.e. X and Y),
[math] \begin{align} x = R\cos(\theta) \\ y = R\sin(\theta) \end{align} [/math]
.
Alternatively,
[math] x =\cos(2\pi U_2)\sqrt{2\ln U_1}\, [/math] and
[math] y =\sin(2\pi U_2)\sqrt{2\ln U_1}\, [/math]
Note: In steps 2 and 3, we are using a similar technique as that used in the inverse transform method.
The BoxMuller Transformation Method generates a pair of independent Standard Normal distributions, X and Y (Using the transformation of polar coordinates).
>>close all >>clear all >>u1=rand(1,1000); >>u2=rand(1,1000); >>d=2*log(u1); >>tet=2*pi*u2; >>x=d.^0.5.*cos(tet); >>y=d.^0.5.*sin(tet); >>hist(tet) >>hist(d) >>hist(x) >>hist(y)
"Remember: For the above code to work the "." needs to be after the d to ensure that each element of d is raised to the power of 0.5.
Otherwise matlab will raise the entire matrix to the power of 0.5."
Note:
the first graph is hist(tet) and it is a uniform distribution.
The second one is hist(d) and it is a exponential distribution.
The third one is hist(x) and it is a normal distribution.
The last one is hist(y) and it is also a normal distribution.
Attention:There is a "dot" between sqrt(d) and "*". It is because d and tet are vectors.
As seen in the histograms above, X and Y generated from this procedure have a standard normal distribution.
>>close all >>clear all >>x=randn(1,1000); >>hist(x) >>hist(x+2) >>hist(x*2+2)
Note: randn is random sample from a standard normal distribution.
Note: hist(x+2) will be centered at 2 instead of at 0.
hist(x*3+2) is also centered at 2. The mean doesn't change, but the variance of x*3+2 becomes nine times (3^2) the variance of x.
Comment: BoxMuller transformations are not computationally efficient. The reason for this is the need to compute sine and cosine functions. A way to get around this timeconsuming difficulty is by an indirect computation of the sine and cosine of a random angle (as opposed to a direct computation which generates U and then computes the sine and cosine of 2πU.
Alternative Methods of generating normal distribution
1. Even though we cannot use inverse transform method, we can approximate this inverse using different functions.One method would be rational approximation.
2.Central limit theorem : If we sum 12 independent U(0,1) distribution and subtract 6 (which is E(ui)*12)we will approximately get a standard normal distribution.
3. Ziggurat algorithm which is known to be faster than BoxMuller transformation and a version of this algorithm is used for the randn function in matlab.
If Z~N(0,1) and X= μ +Zσ then X~[math] N(\mu, \sigma^2)[/math]
If Z_{1}, Z_{2}... Z_{d} are independent identically distributed N(0,1), then Z=(Z_{1},Z_{2}...Z_{d})^{T} ~N(0, I_{d}), where 0 is the zero vector and I_{d} is the identity matrix.
For the histogram, the constant is the parameter that affect the center of the graph.
Proof of Box Muller Transformation
Definition: A transformation which transforms from a twodimensional continuous uniform distribution to a twodimensional bivariate normal distribution (or complex normal distribution).
Let U_{1} and U_{2} be independent uniform (0,10) random variables. Then [math]X_{1} = 2lnU_{1}*cos(2\pi U_{2})[/math]
[math]X_{1} = 2lnU_{1}*sin(2\pi U_{2})[/math] are independent N(0,1) random variables.
This is a standard transformation problem. The joint distribution is given by
f(x1 ,x2) = f_{u1}, _{u2}(g1^− 1(x1,x2),g2^− 1(x1,x2)) *  J
where J is the Jacobian of the transformation,
J = ∂u_{1}/∂x_{1},∂u_{1}/∂x_{2} ∂u_{2}/∂x_{1},∂u_{2}/∂x_{2}
where
u_{1} = g_{1} ^1(x1,x2) u_{2} = g_{2} ^1(x1,x2)
Inverting the above transformations, we have
u1 = exp^{(x_{1} ^2+ x_{2} ^2)/2} u2 = (1/2pi)*tan^1 (x_{2}/x_{1})
Finally we get
f(x1,x2) = {exp^((x1^2+x2^2)/2)}/2pi
which factors into two standard normal pdfs.
General Normal distributions
General normal distribution is a special version of normal distribution. The domain of the general normal distribution is affected by the standard deviation and translated by the mean value.
[math] f(x) = \frac{1}{\sigma\sqrt{2\pi}} e^{ \frac{(x\mu)^2}{2\sigma^2} } [/math]
which is almost useless in this course

where [math] \mu [/math] is the mean or expectation of the distribution and [math] \sigma [/math] is standard deviation
The special case of the normal distribution is standard normal distribution, which the variance is 1 and the mean is zero. If X is a general normal deviate, then Z = (X − μ)/σ will have a standard normal distribution.
If Z ~ N(0,1), and we want [math]X [/math]~[math] N(\mu, \sigma^2)[/math], then [math]X = \mu + \sigma * Z[/math] Since [math]E(x) = \mu +\sigma*0 = \mu [/math] and [math]Var(x) = 0 +\sigma^2*1[/math]
If [math]Z_1,...Z_d[/math] ~ N(0,1) and are independent then [math]Z = (Z_1,..Z_d)^{T} [/math]~ [math]N(0,I_d)[/math] ie.
>>close all >>clear all >>z1=randn(1,1000); <generate variable from standard normal distribution >>z2=randn(1,1000); >>z=[z1;z2]; <produce a vector >>plot(z(1,:),z(2,:),'.')
If Z~N(0,Id) and X= [math]\underline{\mu} + \Sigma^{\frac{1}{2}} \,Z [/math] then [math]\underline{X}[/math] ~[math]N(\underline{\mu},\Sigma)[/math]
NonStandard Normal Distributions
Example 1: Singlevariate Normal
If X ~ Norm(0, 1) then (a + bX) has a normal distribution with a mean of [math]\displaystyle a[/math] and a standard deviation of [math]\displaystyle b[/math] (which is equivalent to a variance of [math]\displaystyle b^2[/math]). Using this information with the BoxMuller transform, we can generate values sampled from some random variable [math]\displaystyle Y\sim N(a,b^2) [/math] for arbitrary values of [math]\displaystyle a,b[/math].
The values for v generated in this way will be equivalent to sample from a [math]\displaystyle N(a, b^2)[/math]distribution. We can modify the MatLab code used in the last section to demonstrate this. We just need to add one line before we generate the histogram:
v = a + b * x;
For instance, this is the histogram generated when b = 15, a = 125:
Example 2: Multivariate Normal
The BoxMuller method can be extended to higher dimensions to generate multivariate normals. The objects generated will be nx1 vectors, and their variance will be described by nxn covariance matrices.
[math]\mathbf{z} = N(\mathbf{u}, \Sigma)[/math] defines the n by 1 vector [math]\mathbf{z}[/math] such that:
If [math]\displaystyle z_1, z_2, ..., z_d[/math] are normal variables with mean 0 and variance 1, then the vector [math]\displaystyle (z_1, z_2,..., z_d) [/math] has mean 0 and variance [math]\!I[/math], where 0 is the zero vector and [math]\!I[/math] is the identity matrix. This fact suggests that the method for generating a multivariate normal is to generate each component individually as single normal variables.
The mean and the covariance matrix of a multivariate normal distribution can be adjusted in ways analogous to the single variable case. If [math]\mathbf{z} \sim N(0,I)[/math], then [math]\Sigma^{1/2}\mathbf{z}+\mu \sim N(\mu,\Sigma)[/math]. Note here that the covariance matrix is symmetric and nonnegative, so its square root should always exist.
We can compute [math]\mathbf{z}[/math] in the following way:
The following MatLab code provides an example, where a scatter plot of 10000 random points is generated. In this case x and y have a covariance of 0.9  a very strong positive correlation.
x = zeros(10000, 1); y = zeros(10000, 1); for ii = 1:10000 u1 = rand; u2 = rand; R2 = 2 * log(u1); theta = 2 * pi * u2; x(ii) = sqrt(R2) * cos(theta); y(ii) = sqrt(R2) * sin(theta); end E = [1, 0.9; 0.9, 1]; [u s v] = svd(E); root_E = u * (s ^ (1 / 2)) * u'; z = (root_E * [x y]'); z(1,:) = z(1,:) + 0; z(2,:) = z(2,:) + 3; scatter(z(1,:), z(2,:))
Note: The svd command computes the matrix singular value decomposition.
[u,s,v] = svd(E) produces a diagonal matrix s of the same dimension as E, with nonnegative diagonal elements in decreasing order, and unitary matrices u and v so that E = u*s*v'.
This code generated the following scatter plot:
In Matlab, we can also use the function "sqrtm()" or "chol()" (Cholesky Decomposition) to calculate square root of a matrix directly. Note that the resulting root matrices may be different but this does materially affect the simulation. Here is an example:
E = [1, 0.9; 0.9, 1]; r1 = sqrtm(E); r2 = chol(E);
R code for a multivariate normal distribution:
n=10000; r2<2*log(runif(n)); theta<2*pi*(runif(n)); x<sqrt(r2)*cos(theta); y<sqrt(r2)*sin(theta); a<matrix(c(x,y),nrow=n,byrow=F); e<matrix(c(1,.9,09,1),nrow=2,byrow=T); svde<svd(e); root_e<svde$u %*% diag(svde$d)^1/2; z<t(root_e %*%t(a)); z[,1]=z[,1]+5; z[,2]=z[,2]+ 8; par(pch=19); plot(z,col=rgb(1,0,0,alpha=0.06))
Bernoulli Distribution
The Bernoulli distribution is a discrete probability distribution, which usually describe an event that only has two possible results, i.e. success or failure. If the event succeed, we usually take value 1 with success probability p, and take value 0 with failure probability q = 1  p.
P ( x = 0) = q = 1  p
P ( x = 1) = p
P ( x = 0) + P (x = 1) = p + q = 1
If X~Ber(p), its pdf is of the form [math]f(x)= p^{x}(1p)^{(1x)}[/math], x=0,1
P is the success probability.
The Bernoulli distribution is a special case of binomial distribution, which the variate x only has two outcomes; so that the Bernoulli also can use the probability density function of the binomial distribution with the variate x only take 0 and 1.
Let x1,s2 denote the lifetime of 2 independent particles, x1~exp([math]lambda[/math]), x2~exp([math]lambda[/math]) we are interested in y=min(x1,x2)
Procedure: To simulate the event of flipping a coin, let P be the probability of flipping head and X = 1 and 0 represent flipping head and tail respectively: 1. Draw U ~ Uniform(0,1) 2. If U <= P X = 1 Else X = 0 3. Repeat as necessary
An intuitive way to think of this is in the coin flip example we discussed in a previous lecture. In this example we set p = 1/2 and this allows for 50% of points to be heads or tails.
i = 1; while (i <=1000) u =rand(); p = 0.3; if (u <= p) x(i) = 1; else x(i) = 0; end i = i + 1; end hist(x)
However, we know that if [math]\begin{align} X_i \sim Bernoulli(p) \end{align}[/math] where each [math]\begin{align} X_i \end{align}[/math] is independent,
[math]U = \sum_{i=1}^{n} X_i \sim Binomial(n,p)[/math]
So we can sample from binomial distribution using this property.
Note: For Binomial distribution, we can consider it as a set of n Bernoulli add together.
p = 0.3; n = 10; for k=1:5000 i = 1; while (i <= n) u=rand(); if (u <= p) y(i) = 1; else y(i) = 0; end i = i + 1; end x(k) = sum(y==1); end hist(x)
Note: We can also regard the Bernoulli Distribution as either a conditional distribution or [math]f(x)= p^{x}(1p)^{(1x)}[/math], x=0,1.
Comments on Matlab: When doing operations on vectors, always put a dot before the operator if you want the operation to be done to every element in the vector. example: Let V be a vector with dimension 2*4 and you want each element multiply by 3.
The Matlab code is 3.*V
some examples for using code to generate distribution.
Class 7  Tuesday, May 28
Note that the material in this lecture will not be on the exam; it was only to supplement what we have learned.
Universality of the Uniform Distribution/Inverse Method
The inverse method is universal in the sense that we can potentially sample from any distribution where we can find the inverse of the cumulative distribution function.
Procedure:
1.Generate U~Unif [0, 1)
2.set [math]x=F^{1}(u)[/math]
3.X~f(x)
Example 1
Let [math]X[/math]_{1},[math]X[/math]_{2} denote the lifetime of two independent particles:
[math]X[/math]_{1}~exp([math]\lambda[/math]_{1})
[math]X[/math]_{2}~exp([math]\lambda[/math]_{2})
We are interested in [math]y=min(X[/math]_{1}[math],X[/math]_{2}[math])[/math]
Design an algorithm based on the InverseTransform Method to generate samples according to [math]f[/math]_{y}[math](y)[/math]
Solution:
x~exp([math]\lambda[/math])
[math]f_{x}(x)=\lambda e^{\lambda x},x\geq0 [/math]
[math]1F_Y(y) = P(Y\gt y)[/math] = P(min(X_{1},X_{2}) > y) = [math]\, P((X_1)\gt y) P((X_2)\gt y) = e^{\, (\lambda_1 + \lambda_2) y}[/math]
[math]F_Y(y)=1e^{\, (\lambda_1 + \lambda_2) y}, y\geq 0[/math]
[math]U=1e^{\, (\lambda_1 + \lambda_2) y}[/math] => [math]y=\, {\frac {1}{{\lambda_1 +\lambda_2}}} ln(1u)[/math]
Procedure:
Step1: Generate U~ U(0, 1)
Step2: set [math]x=\, {\frac {1}{{\lambda_1 +\lambda_2}}} ln(u)[/math]
If we generalize this example from two independent particles to n independent particles we will have:
[math]X[/math]_{1}~exp([math]\lambda[/math]_{1})
[math]X[/math]_{2}~exp([math]\lambda[/math]_{2})
...
[math]X[/math]_{n}~exp([math]\lambda[/math]_{n})
.
And the algorithm using the inversetransform method as follows:
step1: Generate U~U(0,1)
Step2: [math]y=\, {\frac {1}{{ \sum\lambda_i}}} ln(1u)[/math]
Example 2
Consider U~Unif[0,1)
[math]X=\, a (1\sqrt{1u})[/math],
where a>0 and a is a real number
What is the distribution of X?
Solution:
We can find a form for the cumulative distribution function of X by isolating U as U~Unif[0,1) will take values from the range of F(X)uniformly. It then remains to differentiate the resulting form by X to obtain the probability density function.
[math]X=\, a (1\sqrt{1u})[/math]
=>[math]1\frac {x}{a}=\sqrt{1u}[/math]
=>[math]u=1(1\frac {x}{a})^2[/math]
=>[math]u=\, {\frac {x}{a}} (2\frac {x}{a})[/math]
[math]f(x)=\frac {dF(x)}{dx}=\frac {2}{a}\frac {2x}{a^2}=\, \frac {2}{a} (1\frac {x}{a})[/math]
Example 3
Suppose F_{X}(x) = x^{n}, 0 ≤ x ≤ 1, n ∈ N > 0. Generate values from X.
Solution:
1. generate u ~ Unif[0, 1)
2. Set x < U^{1/n}
For example, when n = 20,
u = 0.6 => x = u_{1/20} = 0.974
u = 0.5 => x = u_{1/20} = 0.966
u = 0.2 => x = u_{1/20} = 0.923
Observe from above that the values of X for n = 20 are close to 1, this is because we can view X^{n} as the maximum of n independent random variables X, X~Unif(0,1) and is much likely to be close to 1 as n increases. This observation is the motivation for method 2 below.
Recall that
If Y = max (X_{1}, X_{2}, ... , X_{n}), where X_{1}, X_{2}, ... , X_{n} are independent,
F_{Y}(y) = P(Y ≤ y) = P(max (X_{1}, X_{2}, ... , X_{n}) ≤ y) = P(X_{1} ≤ y, X_{2} ≤ y, ... , X_{n} ≤ y) = F_{x1}(y) F_{x2}(y) ... F_{xn}(y)
Similarly if [math] Y = min(X_1,\ldots,X_n)[/math] then the cdf of [math]Y[/math] is [math]F_Y = 1 [/math][math]\prod[/math][math](1 F_{X_i})[/math]
Method 1: Following the above result we can see that in this example, F_{X} = x^{n} is the cumulative distribution function of the max of n uniform random variables between 0 and 1 (since for U~Unif(0, 1), F_{U}(x) =
Method 2: generate X by having a sample of n independent U~Unif(0, 1) and take the max of the n samples to be x. However, the solution given above using inversetransform method only requires generating one uniform random number instead of n of them, so it is a more efficient method.
generate the Y = max (X1, X2, ... , Xn), Y = min (X1, X2, ... , Xn), pdf and cdf, but (xi and xj are independent) i,j=1,2,3,4,5.....
Example 4 (New)
Now, we are having an similar example as example 1 just doing the maximum way.
Let X_{1},X_{2} denote the lifetime of two independent particles:
[math]\, X_1, X_2 \sim exp(\lambda)[/math]
We are interested in Z=max(X_{1},X_{2})
Design an algorithm based on the InverseTransform Method to generate samples according to f_{Z}(z)
[math]\, F_Z(z)=P[Z\lt =z] = F_{X_1}(z) \cdot F_{X_2}(z) = (1e^{\lambda z})^2[/math]
[math] \text{thus } F^{1}(z) = \frac{1}{\lambda}\log(1\sqrt z)[/math]
To sample Z:
[math]\, \text{Step 1: Generate } U \sim U[0,1)[/math]
[math]\, \text{Step 2: Let } Z = \frac{1}{\lambda}\log(1\sqrt U)[/math], therefore we can generate random variable of Z.
Discrete Case:
u~unif(0,1)
x < 0, S < P_{0}
while u < S
x < x + 1
S < S + P_{0}
Return x
Decomposition Method
The CDF, F, is a composition if [math]F_{X}(x)[/math] can be written as:
[math]F_{X}(x) = \sum_{i=1}^{n}p_{i}F_{X_{i}}(x)[/math] where
1) p_{i} > 0
2) [math]\sum_{i=1}^{n}[/math]p_{i} = 1.
3) [math]F_{X_{i}}(x)[/math] is a CDF
The general algorithm to generate random variables from a composition CDF is:
1) Generate U, V ~ [math]U(0,1)[/math]
2) If u < p_{1}, v=[math]F_{X_{1}}(x)[/math]^{1}
3) Else if u < p_{1}+p_{2}, v=[math]F_{X_{2}}(x)[/math]^{1}
4) ....
Explanation
Each random variable that is a part of X contributes [math]p_{i} F_{X_{i}}(x)[/math] to [math]F_{X}(x)[/math] every time.
From a sampling point of view, that is equivalent to contributing [math]F_{X_{i}}(x)[/math] [math]p_{i}[/math] of the time. The logic of this is similar to that of the AcceptReject Method, but instead of rejecting a value depending on the value u takes, we instead decide which distribution to sample it from.
Examples of Decomposition Method
Example 1
[math]f(x) = \frac{5}{12}(1+(x1)^4) 0\leq x\leq 2[/math]
[math]f(x) = \frac{5}{12}+\frac{5}{12}(x1)^4 = \frac{5}{6} (\frac{1}{2})+\frac {1}{6}(\frac{5}{2})(x1))^4[/math]
Let[math]f_{x_1}= \frac{1}{2}[/math] and [math]f_{x_2} = \frac {5}{2}(x1)^4[/math]
Algorithm:
Generate U~Unif(0,1)
If [math]0\lt u\lt \frac {5}{6}[/math], then we sample from f_{x1}
Else if [math]\frac{5}{6}\lt u\lt 1[/math], we sample from f_{x2}
We can find the inverse CDF of f_{x2} and utilize the Inverse Transform Method in order to sample from f_{x2}
Sampling from f_{x1} is more straightforward since it is uniform over the interval (0,2)
divided f(x) to two pdf of x1 and x2, with uniform distribution, of two range of uniform.
Example 2
[math]f(x)=\frac{1}{4}e^{x}+2x+\frac{1}{12}, \quad 0\leq x \leq 3 [/math]
We can rewrite f(x) as [math]f(x)=(\frac{1}{4}) e^{x}+(\frac{2}{4}) 4x+(\frac{1}{4}) \frac{1}{3}[/math]
Let f_{x1} = [math]e^{x}[/math], f_{x2} = 4x, and f_{x3} = [math]\frac{1}{3}[/math]
Generate U~Unif(0,1)
If [math]0\lt u\lt \frac{1}{4}[/math], we sample from f_{x1}
If [math]\frac{1}{4}\leq u \lt \frac{3}{4}[/math], we sample from f_{x2}
Else if [math]\frac{3}{4} \leq u \lt 1[/math], we sample from f_{x3}
We can find the inverse CDFs of f_{x1} and f_{x2} and utilize the Inverse Transform Method in order to sample from f_{x1} and f_{x2}
We find F_{x1} = [math] 1e^{x}[/math] and F_{x2} = [math]2x^{2}[/math]
We find the inverses are [math] X = ln(1u)[/math] for F_{x1} and [math] X = \sqrt{\frac{U}{2}}[/math] for F_{x2}
Sampling from f_{x3} is more straightforward since it is uniform over the interval (0,3)
In general, to write an efficient algorithm for:
[math]F_{X}(x) = p_{1}F_{X_{1}}(x) + p_{2}F_{X_{2}}(x) + ... + p_{n}F_{X_{n}}(x)[/math]
We would first calculate [math] {q_i} = \sum_{j=1}^i p_j, \forall i = 1,\dots, n[/math]
Then Generate [math] U \sim~ Unif(0,1) [/math]
If [math] U \lt q_1 [/math] sample from [math] f_1 [/math]
else if [math] u\lt q_i [/math] sample from [math] f_i [/math] for [math] 1 \lt i \lt n [/math]
else sample from [math] f_n [/math]
when we divided the pdf of different range of f(x1) f(x2) and f(x3), and generate all of them and inverse, U~U(0,1)
Example of Decomposition Method
F_{x}(x) = 1/3*x+1/3*x^{2}+1/3*x^{3}, 0<= x<=1
let U =F_{x}(x) = 1/3*x+1/3*x^{2}+1/3*x^{3}, solve for x.
P_{1}=1/3, F_{x1}(x)= x, P_{2}=1/3,F_{x2}(x)= x^{2}, P_{3}=1/3,F_{x3}(x)= x^{3}
Algorithm:
Generate U ~ Unif [0,1)
Generate V~ Unif [0,1)
if 0<u<1/3, x = v
else if u<2/3, x = v^{1/2}
else x = v^{1/3}
Matlab Code:
u=rand v=rand if u<1/3 x=v elseif u<2/3 x=sqrt(v) else x=v^(1/3) end
Fundamental Theorem of Simulation
Consider two shapes, A and B, where B is a subshape (subset) of A. We want to sample uniformly from inside the shape B. Then we can sample uniformly inside of A, and throw away all samples outside of B, and this will leave us with a uniform sample from within B. (Basis of the AcceptReject algorithm)
The advantage of this method is that we can sample a unknown distribution from a easy distribution. The disadvantage of this method is that it may need to reject many points, which is inefficient.
inverse each part of partial CDF, the partial CDF is divided by the original CDF, partial range is uniform distribution.
Practice Example from Lecture 7
Let X1, X2 denote the lifetime of 2 independent particles, X1~exp([math]\lambda_{1}[/math]), X2~exp([math]\lambda_{2}[/math])
We are interested in Y = min(X1, X2)
Design an algorithm based on the Inverse Method to generate Y
[math]f_{x_{1}}(x)=\lambda_{1} e^{(\lambda_{1}x)},x\geq0 \Rightarrow F(x1)=1e^{(\lambda_{1}x)}[/math]
[math]f_{x_{2}}(x)=\lambda_{2} e^{(\lambda_{2}x)},x\geq0 \Rightarrow F(x2)=1e^{(\lambda_{2}x)}[/math]
[math]then, 1F(y)=p(min(x_{1},x_{2}) \geq y)=e^{((\lambda_{1}+\lambda_{2})y)},F(y)=1e^{((\lambda_{1}+\lambda_{2}) y)}[/math])
[math]u \sim unif[0,1),u = F(x),\geq y = 1/(\lambda_{1}+\lambda_{2})log(1u)[/math]
Question 2
Use Acceptance and Rejection Method to sample from [math]f_X(x)=b*x^n*(1x)^n[/math] , [math]n\gt 0[/math], [math]0\lt x\lt 1[/math]
Solution: This is a beta distribution, Beta ~[math]\int _{0}^{1}b*x^{n}*(1x)^{n}dx1[/math]
U_{1~Unif[0,1) }
U_{2~Unif[0,1)
}
fx=[math] bx^{1/2}(1x)^{1/2} \lt = bx^{1/2}\sqrt2 ,0\lt =x\lt =1/2 [/math]
The beta distribution maximized at 0.5 with value [math](1/4)^n[/math]. So, [math]c=b*(1/4)^n[/math] Algorithm: 1.Draw [math]U_1[/math] from [math]U(0, 1)[/math].[math] U_2[/math] from [math]U(0, 1)\lt math\gt 2.If \lt math\gt U_2\lt =b*(U_1)^n*(1(U_1))^n/b*(1/4)^n=(4*(U_1)*(1(U_1)))^n[/math]
then X=U_1 Else return to step 1.
Discrete Case:
Most discrete random variables do not have a closed form inverse CDF. Also, its CDF [math]F:X \rightarrow [0,1][/math] is not necessarily onto. This means that not every point in the interval [math] [0,1] [/math] has a preimage in the support set of X through the CDF function.
Let [math]X[/math] be a discrete random variable where [math]a \leq X \leq b[/math] and [math]a,b \in \mathbb{Z}[/math] .
To sample from [math]X[/math], we use the partition method below:
[math]\, \text{Step 1: Generate u from } U \sim Unif[0,1][/math]
[math]\, \text{Step 2: Set } x=a, s=P(X=a)[/math]
[math]\, \text{Step 3: While } u\gt s, x=x+1, s=s+P(X=x)[/math]
[math]\, \text{Step 4: Return } x[/math]
Class 8  Thursday, May 30, 2013
In this lecture, we will discuss algorithms to generate 3 wellknown distributions: Binomial, Geometric and Poisson. For each of these distributions, we will first state its general understanding, probability mass function, expectation and variance. Then, we will derive one or more algorithms to sample from each of these distributions, and implement the algorithms on Matlab.
The Bernoulli distribution
The Bernoulli distribution is a special case of the binomial distribution, where n = 1. X ~ Bin(1, p) has the same meaning as X ~ Ber(p), where p is the probability if the event success, otherwise the probability is 1p (we usually define a variate q, q= 1p). The mean of Bernoulli is p, variance is p(1p). Bin(n, p), is the distribution of the sum of n independent Bernoulli trials, Ber(p), each with the same probability p, where 0<p<1.
For example, let X be the event that a coin toss results in a "head" with probability p, then X~Bernoulli(p).
P(X=1)=p,P(X=0)=1p, P(x=0)+P(x=1)=p+q=1
Algorithm:
1. Generate u~Unif(0,1)
2. If u ≤ p, then x = 1
else x = 0
The answer is:
when U≤p, x=1
when U>p, x=0
3.Repeat as necessary
The Binomial Distribution
If X~Bin(n,p), then its pmf is of form:
f(x)=(nCx) p^{x}(1p)^{(nx)}, x=0,1,...n
Or f(x) = [math](n!/x!(nx)!)[/math] p^{x}(1p)^{(nx)}, x=0,1,...n
Mean (x) = E(x) = [math] np [/math]
Variance = [math] np(1p) [/math]
Generate n uniform random number [math]U_1,...,U_R[/math] and let X be the number of [math]U_i[/math] that are less than or equal to p.
The logic behind this algorithm is that the Binomial Distribution is simply a Bernoulli Trial, with a probability of success of p, repeated n times. Thus, we can sample from the distribution by sampling from n Bernoulli. The sum of these n bernoulli trials will represent one binomial sampling. Thus, in the below example, we are sampling 1000 realizations from 20 Bernoulli random variables. By summing up the rows of the 20 by 1000 matrix that is produced, we are summing up the 20 bernoulli outcomes to produce one binomial sampling. We have 1000 rows, which means we have realizations from 1000 binomial random variables when this sum is done (the output of the sum is a 1 by 1000 sized vector).
To continue with the previous example, let X be the number of heads in a series of n independent coin tosses  where for each toss, the probability of coming up with a head is p  then X~Bin(n, p).
MATLAB tips: to get a pdf f(x), we can use code binornd(N,P). N means number of trails and p is the probability of success. a=[2 3 4],if set a<3, will produce a=[1 0 0]. If you set "a == 3", it will produce [0 1 0]. If a=[2 6 9 10], if set a<4, will produce a=[1 0 0 0], because only the first element (2) is less than 4, meanwhile the rest are greater. So we can use this to get the number which is less than p.
Algorithm for Bernoulli is given as above
Code
>>a=[3 5 8]; >>a<5 ans= 1 0 0 >>rand(20,1000) >>rand(20,1000)<0.4 >>A = sum(rand(20,1000)<0.4) >>hist(A) >>mean(A) Note: `1` in the above code means sum the matrix by column >>sum(sum(rand(20,1000)<0.4)>8)/1000 This is an estimate of Pr[A>8].
remark: a=[2 3 4],if set a<3, will produce a=[1 0 0]. If you set "a == 3", it will produce [0 1 0]. using code to find some value what i want to get from the matrix. It`s useful to define some matrixs.
Relation between Bernoulli Distribution and Binomial Distribution: For instance, we want to find numbers ≤0.3. Uniform collects which is ≤0.3, and Binomial calculates how many numbers are there ≤0.3.
The Geometric Distribution
Geometric distribution is a discrete distribution. There are two types geometric distributions, the first one is the probability distribution of the number of X Bernoulli fail trials, with probability 1p, needed until the first success situation happened, X come from the set { 1, 2, 3, ...}; the other one is the probability distribution of the number Y = X − 1 of failures, with probability 1p, before the first success, Y comes from the set { 0, 1, 2, 3, ... }.
For example, If the success event showed at the first time, which x=1, then f(x)=p. If the success event showed at the second time and failed at the first time, which x=2, then f(x)=p(1p). If the success event showed at the third time and failed at the first and second time, which x=3, then f(x)=p(1p)^2. etc. If the success event showed at the x time and all failed before time x, which x=x, then f(x)=p(1p)ˆ(x1)
For example, suppose a die is thrown repeatedly until the first time a "6" appears. This is a question of geometric distribution of the number of times on the set { 1, 2, 3, ... } with p = 1/6.
General speaking, if X~G(p) then its pdf is of the form f(x)=(1p)^{(x1)}*p, x=1,2,...
The random variable X is the number of trials required until the first success in a series of independent Bernoulli trials.
Other properties
Probability mass function : P(X=k) = P[math](1p)^(k1)[/math]
Tail probability : P(X>n) = [math](1p)^n[/math]
The CDF : P(X<n) = 1  [math](1p)^n[/math]
Mean of x = 1/p Var(x) = (1p)/p^2
There are two ways to look at a geometric distribution.
1st Method
We look at the number of trials before the first success. This includes the last trial in which you succeeded. This will be used in our course.
pdf is of form f(x)=>(1p)^{(x1)}*(p), x = 1, 2, 3, ...
2nd Method
This involves modeling the failure before the first success. This does not include the last trial in which we succeeded.
pdf is of form f(x)=> ((1p)^x)*p , x = 0, 1, 2, ....
If Y~Exp([math]\lambda[/math]) then X=floor(Y)+1 is geometric.
Choose e^([math]\lambda[/math])=1p. Then X ~ geo (p)
P (X > x) = (1p)^{x}(because first x trials are not successful)
Proof
P(X>x) = P( floor(Y) + 1 > X) = P(floor (Y) > x 1) = P(Y>= x) = e^{([math]\lambda[/math] * x)}
SInce p = 1 e^{[math]\lambda[/math]} or [math]\lambda[/math]= [math]log(1p)[/math], then
P(X>x) = e^{([math]\lambda[/math] * x)} = e^{log(1p)*x} = (1p)^{x}
Note that floor(Y)>X > Y >= X+1
proof how to use EXP distribution to find P(X>x)=(1p)^x
Suppose X has the exponential distribution with rate parameter [math] \lambda \gt 0 [/math]
the [math]\left \lfloor X \right \rfloor [/math] and [math]\left \lceil X \right \rceil [/math] have geometric distribution on [math] \mathcal{N} [/math] and [math] \mathcal{N}_{+} [/math] respectively each with success probability [math] 1e^ { \lambda} [/math]
Proof:
[math]\text{For } n \in \mathcal{N} [/math]
[math]\begin{align}
P(\left \lfloor X \right \rfloor = n)&{}= P( n \leq X \lt n+1) \\
&{}= F( n+1)  F(n) \\
\text{By algebra and simplification:} \\
P(\left \lfloor X \right \rfloor = n)&{}= (e^ {\lambda})^n \cdot (1  e^ {\lambda}) \\
&{}= Geo (1  e^ {\lambda}) \\
\text{Proof of ceiling part follows immediately.} \\
\end{align}[/math]
Algorithm:
1) Let [math]\lambda = \log (1p) [/math]
2) Generate a [math]Y \sim Exp(\lambda )[/math]
3) We can then let [math]X = \left \lfloor Y \right \rfloor + 1, where X\sim Geo(p)[/math]
note: [math]\left \lfloor Y \right \rfloor \gt 2 \gt Y\gt =3[/math]
[math] \left \lfloor Y \right \rfloor \gt 5 \gt Y\gt =6[/math]
[math]\left \lfloor Y \right \rfloor\gt x [/math] > Y>= X+1
[math]P(Y\gt =X)[/math]
Y ~ Exp ([math]\lambda[/math])
pdf of Y : [math]\lambda e^{\lambda}[/math]
cdf of Y : [math]1\lambda e^{\lambda}[/math]
cdf [math]P(Y\lt x)=1\lambda e^{\lambda}[/math]
[math]P(Y\gt =x)=1(1\lambda e^{\lambda})=e^{\lambda x}[/math]
[math] e^{\lambda}=1p \gt log(1p)=\lambda[/math]
[math]P(Y\gt =x)=e^{\lambda x}=e^{log(1p)x}=(1p)^x[/math]
[math]E[x]=1/P [/math]
[math]Var= (1P)/(P^2)[/math]
P(X>x)
=P(floor(y)+1>x)
=P(floor(y)>x1)
=P(y>=x)
use e^(mu)=(1p) to figure out the mean and variance.
Code
>>p=0.4; >>l=log(1p); >>u=rand(1,1000); >>y=(1/l)*log(u); >>x=floor(y)+1; >>hist(x) ===Note:=== mean(x)~E[X]=> 1/p Var(x)~V[X]=> (1p)/p^2
Note that the above mean is the average amount of times you should try until you get a successful case.
Poisson Distribution
If [math]\displaystyle X \sim \text{Poi}(\lambda)[/math], its pdf is of the form [math]\displaystyle \, f(x) = \frac{e^{\lambda}\lambda^x}{x!}[/math] , where [math]\displaystyle \lambda [/math] is the rate parameter.
Understanding of Poisson distribution:
If customers independently come to bank over time, all following exponential distributions with rate [math]\lambda[/math] per unit of time, then X(t) = # of customer in [0,t] ~ Poi[math](\lambda t)[/math]
Its mean and variance are
[math]\displaystyle E[X]=\lambda[/math]
[math]\displaystyle Var[X]=\lambda[/math]
A Poisson random variable X can be interpreted as the maximal number of i.i.d. (Independent and Identically Distributed) exponential variables(with parameter [math]\lambda[/math]) whose sum does not exceed 1.
The traditional understanding of the Poisson distribution as the total number of events in a specific interval can be understood here since the above definition simply describes the Poisson as the sum of waiting times for n events in an interval of length 1.
[math]\displaystyle\text{Let } Y_j \sim \text{Exp}(\lambda), U_j \sim \text{Unif}(0,1)[/math]
[math]Y_j = \frac{1}{\lambda}\log(U_j) \text{ from Inverse Transform Method}[/math]
[math]\begin{align}
X &= \max \{ n: \sum_{j=1}^{n} Y_j \leq 1 \} \\
&= \max \{ n: \sum_{j=1}^{n}  \frac{1}{\lambda}\log(U_j) \leq 1 \} \\
&= \max \{ n: \sum_{j=1}^{n} \log(U_j) \gt \lambda \} \\
&= \max \{ n: \log(\prod_{j=1}^{n} U_j) \gt \lambda \} \\
&= \max \{ n: \prod_{j=1}^{n} U_j \gt e^{\lambda} \} \\
\end{align}[/math]
Note: From above, we can use Logarithm Rules [math]\log(a)+\log(b)=\log(ab)[/math] to generate the result.
Algorithm:
1) Set n=1, a=1
2) Generate [math]U_n ~ U(0,1), a=aU_n [/math]
3) If [math]a \gt = e^{\lambda}[/math] , then n=n+1, and go to Step 2. Else, x=n1
using inversemethod to proof mean and variance of poisson distribution.
MATLAB Code for generating Poisson Distribution
>>l=2; N=1000 >>for ii=1:N n=1; a=1; u=rand; a=a*u; while a>exp(l) n=n+1; u=rand; a=a*u; end x(ii)=n1; end >>hist(x) >>Sum(x==1)/N # Probability of x=1 >>Sum(x>3)/N # Probability of x > 3
EXAMPLE for geometric distribution: Consider the case of rolling a die:
X=the number of rolls that it takes for the number 5 to appear.
We have X ~Geo(1/6), [math]f(x)=(1/6)*(5/6)^{x1}[/math], x=1,2,3....
Now, let [math]Y=e^{\lambda}[/math] => x=floor(Y) +1
Let [math]e^{\lambda}=5/6[/math]
[math]P(X\gt x) = P(Y\gt =x)[/math] (from the class notes)
We have [math]e^{\lambda *x} = (5/6)^x[/math]
Algorithm: let [math]\lambda = \log(5/6)[/math]
1) Let Y be [math]e^{\lambda}[/math], exponentially distributed
2) Set X= floor(Y)+1, to generate X
[math] E[x]=6, Var[X]=5/6 /(1/6^2) = 30 [/math]
GENERATING NEGATIVE BINOMIAL RV USING GEOMETRIC RV'S
Property of negative binomial Random Variable:
The negative binomial random variable is a sum of r independent geometric random variables.
Using this property we can formulate the following algorithm:
Step 1: Generate r geometric rv's each with probability p using the procedure presented above.
Step 2: Take the sum of these r geometric rv's. This RV follows NB(r,p)
remark the step 1 and step 2. Looking for the floor Y, and e^(mu)=1p=5/6, and then generate x.
Another way to generate random variable from poisson distribution
Note: [math]P(X=x)=\frac {e^{\lambda}\lambda^x}{x!}, \forall x \in \N[/math]
Let [math]\displaystyle p(x) = P(X=x)[/math] denote the pmf of [math]\displaystyle X[/math].
Then ratio is [math]\frac{p(x+1)}{p(x)}=\frac{\lambda}{x+1}, \forall x \in \N[/math]
Therefore, [math]p(x+1)=\frac{\lambda}{x+1}p(x)[/math]
Algorithm:
1. Set [math]\displaystyle x=0[/math]
2. Set [math]\displaystyle F=p=e^{\lambda}[/math]
3. Generate [math]\displaystyle U \sim~ \text{Unif}(0,1)[/math]
4. If [math]\displaystyle U\lt F[/math], output [math]\displaystyle x[/math]
Else
[math]\displaystyle p=\frac{\lambda}{x+1} p[/math]
[math]\displaystyle F=F+p[/math]
[math]\displaystyle x = x+1[/math]
Go to 4.
This is indeed the inversetransform method, with a clever way to calculate the CDF on the fly.
u=rand(0.1000)
hist(x)
1. set n =1, a = 1
2. set U_{n}~U(0,1), a = a*U_{n}
3. if [math]a \gt e^{\lambda}[/math], then n = n+1, go to step 2,
else x = n1
firstly, find the ratio of x=k+1 to x=k, find out F[x=0],and generate to uniform.
Class 9  Tuesday, June 4, 2013
Beta Distribution
The beta distribution is a continuous probability distribution. There are two shaped parameters in this distribution defined as alpha and beta, both parameters greater than 0, and X within the interval [0,1]. The parameter alpha is used as exponents of the random variable. The parameter beta is used to control the shape of the this distribution. We use the beta distribution to build the model of the behavior of random variables, which are limited to intervals of finite length. For example, we can use the beta distribution to analyze the time allocation of sunshine data and variability of soil properties.
If X~Beta([math]\alpha, \beta[/math]) then its p.d.f. is of the form
and [math]f(x;\alpha,\beta)= 0 [/math] otherwise Note: [math]\Gamma(\alpha)=(\alpha1)! [/math] if [math]\alpha[/math] is a positive integer.
The mean of the beta distribution is [math]\frac{\alpha}{\alpha + \beta}[/math]. The variance is [math]\frac{\alpha\beta}{(\alpha+\beta)^2 (\alpha + \beta + 1)}[/math]
The variance of the beta distribution decreases monotonically if [math] \alpha = \beta [/math] and as [math] \alpha = \beta [/math] increases, the variance decreases.
The formula for the cumulative distribution function of the beta distribution is also called the incomplete beta function ratio (commonly denoted by Ix) and is defined as F(x) = I(x)(p,q)
To generate random variables of a Beta distribution, there are multiple cases depending on the value of [math]\alpha [/math] and [math] \beta [/math]:
Case 1. If [math]\alpha=1[/math] and [math]\beta=1[/math]
Note: 0! = 1.
Hence, the distribution is:
If the Question asks for sampling Beta Distribution, we can sample from Uniform Distribution which we already know how to sample from
Algorithm:
Generate U~Unif(0,1)
Case 2. Either [math]\alpha=1[/math] or [math]\beta=1[/math]
e.g. [math]\alpha=1[/math]
We don't make any assumption about [math]\beta[/math] except that it is a positive integer. <br\>
The CDF is [math]F(x) = x^{\alpha}[/math] (using integration of [math]f(x)[/math]) WIth CDF F(x) = x^α, if U have CDF, it is very easy to sample: y=x^α > x=y^α > inverseF(x)= x^(1/α) U~U(0,1) > x=u^(1/α) Applying the inverse transform method with [math]y = x^\alpha \Rightarrow x = y^\frac {1}{\alpha}[/math]
[math]F(x)^{1} = y^\frac {1}{\alpha}[/math]
between case 1 and case 2, when alpha and beta be different value, the beta distribution can simplify to other distribution.
Algorithm
after simplified we can use other distribution method to solve the problem.
MATLAB Code to generate random n variables using the above algorithm
x = rand(1,n).^(1/alpha)
Case 3. To sample from beta in general. we use the property that <br\>
Note: 1. [math]\alpha[/math] and [math]\beta[/math] are shape parameters here and 1 is the scale parameter.<br\>
2.Exponential: [math]\frac{1}{\lambda} \log(u)[/math] <br\> 3.Gamma: [math]\frac{1}{\lambda} \log(u_1, \cdots, u_t)[/math]<br\>
Algorithm<br\>
Please see the following example for Matlab code.
Case 4. Use The AcceptanceRejection Method <br\>
The beta density is
[math]\displaystyle \text{Beta}(\alpha,\beta) = \frac{\Gamma(\alpha+\beta)}{\Gamma(\alpha)\Gamma(\beta)}x^{\alpha1}(1x)^{\beta1} [/math] where [math]0 \leq x \leq 1[/math]
Assume [math]\alpha,\beta \geq 1[/math]. Then [math]\displaystyle f(x)[/math] has the maximum at [math]\frac{\alpha1}{\alpha+\beta2}[/math].
(Please note that we could find the maximum by taking the derivative of f(x), let f'(x)=0 and then use maximum likelihood estimate to find what the maximum value is)
Define
[math] c=f(\frac{\alpha1}{\alpha+\beta2}[/math]) and choose [math]\displaystyle g(x)=1[/math].
The AR method becomes
1.Generate independent [math]\displaystyle U_1[/math] and [math]\displaystyle U_2[/math] from [math]\displaystyle UNIF[0,1][/math] until [math]\displaystyle cU_2 \leq f(U_1)[/math];
2.Return [math]\displaystyle U_1[/math].
MATLAB Code for generating Beta Distribution
>>Y1 = sum(log(rand(1,1000))) #Gamma(1,1) >>Y2 = sum(log(rand(10,1000))) #Gamma(10,1), we want to generate 1000 samples and want 10 uniform distributions. %NOTE: here, lamda is 1, since the scale parameter for Y1 & Y2 are both 1 >>Y=Y1./(Y1+Y2) #Don't forget to divide elements using "." Where Y follows Beta(10,5) >>figure >>hist(Y1) #Gamma curve >>figure >>hist(Y2) #Gamma curve >>figure >>hist(Y) #Do this to check that the shape fits beta.
This is the histogram of Y, precisely simulated version of Beta (10,5)
This is the pdf of various beta distributions
300px
MATLAB tips: rand(10,1000) produces one 10*1000 matrix and sum(rand(10,1000)) produces a 10*1000 matrix
and each element in the matrix follows CDF of uniform distribution.
Example for the code to explain the beta distribution.
Another MATLAB Code for generating Beta Distribution using AR method
>>alpha = 3 >>beta = 2 >> a = sum (log(rand(alpha,1000))) >> b = sum (log(rand(beta,1000))) >> aandb=sum(log(rand(alpha+beta,1000))) >> t = (alpha  1)/(alpha + beta 2) >> c = (andb/(a*b))*t^(alpha1)*(1t)^(beta1) >> u1 = rand >> u2 = rand >> x = (andb/(a*b))*u1^(alpha1)*(1u1)^(beta1) >> while c*u2>x >> u1 = rand >> u2 = rand >> x = (andb/(a*b))*u1^(alpha1)*(1u1)^(beta1) >> end >> u1
Random Vector Generation
We want to sample from [math]X = (X_1, X_2, [/math]…,[math] X_d)[/math], a ddimensional vector from a known pdf [math]f(x)[/math] and cdf [math]F(x)[/math]. We need to take into account the following two cases:
Case 1
if the [math]x_1, x_2 \cdots, x_d[/math]'s are independent, then
[math]f(x) = f(x_1,\cdots, x_d) = f(x_1)\cdots f(x_d)[/math]
we can sample from each component [math]x_1, x_2,\cdots, x_d[/math] individually, and then form a vector.
based independent rule to show the pdf or pmf of [math]x=x_1,x_2,x_3,x_4,x_5,\cdots[/math]
Case 2
If [math]X_1, X_2,[/math], ..., [math]X_d[/math] are not independent
[math]f(x) = f(x_1[/math], ..., [math]x_d) = f(x_1) f(x_2x_1)[/math]...[math]f(x_dx_(d1)[/math],… ,[math]x_1)[/math]
we need to know the conditional distributions of [math]f(x_2x_1), f(x_3x_2, x_1),[/math] …, [math]f(x_dx_(d1)[/math],…,[math]x_1)[/math]
This is generally a hard problem. Conditional probabilities are not easy to compute, then sampling from these would be based on your statistics knowledge.
In each case, we have to consider the previous cases.
[math]f(x_1)[/math] is onedimensional, some as [math]f(x_2x_1)[/math] and all others.
In general, one could consider the covariance matrix [math] C [/math] of random variables [math] X_1[/math],…,[math]X_d [/math].
Suppose we now have the Cholesky factor [math] G[/math] of [math] C [/math] (i.e. [math] C = GG^T [/math]). In matlabe, we use Chol(C)
For any dtuple [math] X := (X_1 ,\ldots , X_d) [/math] (i.e random variable generated by [math] X_1,\ldots , X_d [/math] respectively)
[math] GX [/math] would yield the desired distribution.
Note
1.) All cases can use this (independent or dependent): [math]f(x) = f(x_1, x_2)= f(x_1) f(x_2x_1)[/math]
2.) If we determine that [math]x_1[/math] and [math] x_2[/math] are independent, then we can use [math]f(x) = f(x_1, x_2)= f(x_1)f(x_2)[/math]
the case show the formula of the X = (X1,X2,…,Xd), a ddimensional vector, when they are not independent of each x. we use conditional function to define the probability function of x with ddimensional.
Example
Generate uniform random vectors
1) x = (x_{1}, …, x_{d}) from the ddimensional rectangle
2) D = { (x_{1}, …, x_{d}) : a_{i} <= x_{i} <= b_{i} , i = 1, …, d}
Algorithm:
1) for i = 1 to d
2) U_{i} ~ U(0,1)
3) x_{i} = a_{i} + U(b_{i}a_{i})
4) end
An example of the 2D case is given below:
>>a=[1 2]; >>b=[4 6]; >>for i=1:2 u(i) = rand(); x(i) = a(i) + (b(i)  a(i))*u(i); end >>hold on => this is to retain current graph when adding new graphs >>rectangle('Position',[1 2 3 4]) => draw the boundary of the rectangle >>axis([0 10 0 10]) => change the size of axes >>plot(x(1),x(2),'.')
Code:
function x = urectangle (d,n,a,b) for ii = 1:d; u(ii,:) = rand(1,n); x(ii,:) = a+ u(ii,:)*(ba); %keyboard #makes the function stop at this step so you can evaluate the variables end >>x=urectangle(2, 100, 2, 5); >>scatter(x(1,:),x(2,:)) >>x=urectangle(2, 10000, 2, 5); #generate 10000 numbers (instead of 100) >>x=urectangle(3, 10000, 2, 5); #changed to 3dimensional >>scatter3(x(1,:), x(2,:), x(3,:)) >>axis square
Vector AcceptanceRejection Method
The acceptancerejection method can be extended to ndimensional cases, with the same concept:
If a random vector is to be generated uniformly from G, an irregular shape in the nth dimension, and W is a regular shape arbitrarily close to G in the nth dimension, then acceptancerejection method can be applied as follows:
1. Sample from the regular shape W
2. Accept sample points if they are inside G
Example: Generate a random vector Z that is uniformly distributed over region G
G: ddimensional unit ball, [math]G = \big\{{x: \sum_{i}{x_i}^2 \leq 1}\big\}[/math]
w: ddimensional hypercube, [math]W = \big\{{1 \leq x_i \leq 1}\big\}_{i=1}^d[/math]
Procedure:
Step 1: [math]U_1 \sim~ U(0,1),\cdots, U_d \sim~ U(0,1)[/math]
Step 2: [math]X_1 = 1  2U_1, \cdots, X_d = 1  2U_d, R = \sum_i X_i^2[/math]
Step 3: If [math]R \leq 1, Z=(X_1, ..... , X_d)[/math]
Else go to step 1
it is an example of the vector A/R, regular shape is W likes f(x), G is c*g(x) <br\>
Class 10  Thursday June 6th 2013
MATLAB code for using Acceptance/Rejection Method to sample from a ddimensional unit ball.
Code:
function output = Unitball(d,n) u = rand(d,n); z = 1 2 *u; R = sum(z.^2); jj=1; for ii=1:n if R(ii)<=1 x(:,jj)=z(:,ii); jj=jj+1; end end output = x; end >> data = Unitball(d, n) >> scatter(data(1,:), data(2,:)) %plot 2d graph R(ii) computes the sum of the square of each element of a vector, so if it is less than 1, then the vector is in the unit ball. x(:,jj) means all the numbers in the jj column. z(:,ii) means all the numbers in the ii column starting from 1st column until the nth column, which is the last one. Save it with the name of the pattern.
Execution: >>[x]=Unitball(2,10000); >>scatter(x(1,:),x(2,:)); %plot 2D circle >>axis square; %make the xy axis has same size >>size(x) ans = 2 7839 >>scatter(x(1,:),x(2,:))
scatter(x(1,:),x(2,:)) the (x(1,:) means all the numbers in the first row are parameter.
Calculate the efficiency:
>>c=7839/10000 %Efficiency = points accepted / total points c = 0.7839
We can use the above program to calculate how many points in the circle condition are in the square.
Estimate [math]\displaystyle \pi[/math]
>> 4*size(x,2)/10000 ans = 3.1356 >> [x]=Unitball(3,10000); >> scatter3(x(1,:),x(2,:),x(3,:)) %plot 3d ball >> axis square >> size(x,2)/10000 %returns the size of the dimension of X specified by scalar 2 ans = 0.5231 >> [x]=Unitball(5,10000); >> size(x,2)/10000 ans = 0.1648
Note that the c increases exponentially as d increases, this cause more points being rejected. This method is not efficient for large values of d.
In practice, when we need to vectorlise high quality image or genes then d would be very large. So AR method is not an efficient way to solve the problem.
Efficiency
In the above example, the efficiency of the vector A/R is equal to the ratio
[math]\frac{1}{C}=\frac{\text{volume of hyperball}}{\text{volume of hybercube}}[/math]
In general, the efficiency can be thought of as the total number of points accepted divided by the total number of points generated.
As the dimension increase, the efficiency of the algorithm will decrease exponentially.
For example, for approximating value of [math]\pi[/math], when [math]d \text{(dimension)} =2[/math], the efficiency is around 0.7869; when [math]d=3[/math], the efficiency is around 0.5244; when [math]d=10[/math], the efficiency is around 0.0026: it is getting close to 0.
Thus, when we want to generate high dimension vectors, AcceptanceRejection Method is not efficient to be used.
Stochastic Process
The basic idea of Stochastic Process (also called random process) is a collection of some random variables, [math]\big\{X_t:t\in T\big\}[/math], where the set X is called the state space that each variable is in it and T is called the index set.
A stochastic process is nondeterministic. This means that there is some indeterminacy in the final state, even if the initial condition is known.
We can illustrate this with an example of speech: if "I" is the first word in a sentence, the set of words that could follow would be limited (eg. like, want, am), and the same happens for the third word and so on. The words then have some probabilities among them such that each of them is a random variable, and the sentence would be a collection of random variables.
Also, Different Stochastic Process has different properties.
In the course, we study two Stochastic Process models.
The two stochastic Process models we will study are:
1. Poisson ProcessThis is continuous time counting process that satisfies a couple of properties that are listed in the next section. The Poisson process is understood to be a good model for events such as incoming phone calls, number of traffic accidents, and goals during a game of hockey or soccer. It is also an example of a birthdeath process.
2. Markov Process This is a stochastic process that satisfies the Markov property which can be understood as the memoryless property. The property states that the jump to a future state only depends on the current state of the process, and not of the process's history. This model is used to model random walks exhibited by particles, the health state of a life insurance policyholder, decision making by a memoryless mouse in a maze, etc.
Stochastic Process means even we get some conditions at the beginning, we just can guess some variables followed the first, but at the end the variable would be unpredictable.
Example
The state space is the set of English words, and [math]x_t[/math] are words that are said. Another example involves the stock market: the set of all nonnegative numbers is the state space, and [math]x_t[/math] are stock prices.
stochastic process always has state space and the index set to limit the range.
The state space is the set of cars , while [math]x_t[/math] are sport cars.
Poisson Process
The Poisson process arises when we count the number of occurrences of events over time.
e.g traffic accidents , arrival of emails. Emails arrive at random time [math]T_1, T_2[/math] ...
Let [math]N_t[/math] denote the number of arrivals in the time interval [math](0,t][/math]<br\> The number of arrivals in the interval [math]I(a,b][/math] denoted by [math]N(a,b][/math] is equal to [math]N_bN_a[/math] the number of arrivals in (a,b] is independent from the number of arrivals in (c,d] where (a,b] and (c,d] do not intersect.
Definition: An arrival counting process [math]N=(N_t)[/math] is called (Homogeneous) Poisson Process (PP) with rate [math]\lambda \gt 0[/math] if
A. The numbers of points in nonoverlapping intervals are independent.
B. The number of points in interval [math]I(a,b][/math] has a poisson distribution with mean [math]\lambda (ba)[/math] ,where (ba) represents the length of I.
How to generate a multivariate normal with build in function "randn": (example)
(please check the general idea at the end of lecture 6 course note.)
z=randn(length(mu),n); %Here length(mu)=2 since s is a 2*2 matrix; s=[1 0.7;0.7 1] A=chol(s) x=mu'*ones(1,n) + A*z; %ones(1,n) is a function expand the size of mu from 1*1 %matrix to 1*n matrix;
and if we want to use boxmuller to generate a multivariate normal, we could use the code in lecture 6:
d = length(mu); R = chol(Sigma); U1=rand(n,d) U2=rand(d,d) D=2*log(U1) tet=2*pi*U2 Z=(D.^0.5)*cos(tet)' %since in lecture 6, we set up x and y are independent normal %distribution, so in here we can choose either cos and sin X = Z*R + ones(n,1)*mu';
Class 11  Tuesday，June 11, 2013
Announcement
Midterm covers up to last lecture (stochastic process), which means stochastic process will not be on midterm. There won't be any Matlab syntax questions.
Poisson Process
A discrete stochastic variable X is said to have a Poisson distribution with parameter λ > 0
(a) Independence: The number of arrivals in non overlapping intervals are independent (i.e. memoryless property of poisson distribution)
(b) Homogeneity or Uniformity: The number of arrival in each interval I[a,b] is Poisson distribution with rate [math]\lambda [/math]x length (I)
(c) Individuality: for a sufficiently short time periods of length h, the probability of 2 or more events occuring in the interval is close to 0
Notation:
N_{t} denotes the number of arrivals up to t. ie:[0,t]
N_{[ba)} = N_{b}  N_{a} denotes the number of arrivals in I(a, b].
For a small interval (t,t+h], where h is small
1. The number of arrivals in this interval is independent of the number of arrivals up to t(Nt)
2. :[math] P (N(t,t+h)=1N_{t} ) = P (N(t,t+h)=1N_{t}) =\frac{e^{\lambda h} (\lambda h)^1}{1!} =e^{\lambda h} {\lambda h} \approx \lambda h [/math]
since e^{([math]\lambda [/math]h)}≈1 when h is small.
[math]\lambda[/math] * h can be thought of as the probability of observing an arrival in the interval t to t+h.
Similarly, the probability of not observing an arrival in this interval is 1[math]\lambda [/math] h.
Generate a Poisson Process
Un~U(0,1)
TnTn1=1/[math]\lambda [/math] * log(Un)
Since P(N(t,t+h)=1) = exp([math]\lambda [/math]h)* [math]\lambda [/math]h, we can regard [math]\lambda [/math]h as a exponential distribution, and according to what we learnt, TnTn1 = h = 1/[math]\lambda [/math] * log(Un)
λh can be thought of as an approximation to the probability of observing an arrival in the interval t to t+h, given that h is small.
Similarly, the probability of not observing an arrival in this interval is 1λh.
Review of Poisson  Example
Let X be the r.v of the number of accidents in an hour. It is distributed poisson (1.8).
P(X=4)=e^(1.8)*(1.8)^4 /4!
P(X>=1) = 1  P(x=o) = 1 e^(1.8)
P(N_{3}>3N_{2})=P(N_{1}>2)
Generating an homogeneous Poisson Process
Un~U(0,1)
TnTn1=1/[math]\lambda [/math] * log(Un)
The waiting time between each occurrence follows the exponential distribution with parameter [math]\lambda [/math]. [math]T_n[/math] represents the time elapsed at the n^{th} occurence.
1) Set T_{0} = 0 and n = 1
2) U_{n} follow U(0,1)
3) T_{n}  T_{n1} = 1/[math]\lambda [/math] * log (u) (Declare an arrival)
4) if T_{n} >T stop;
else n = n + 1, go to step 2
MatLab Code
T(1)=0; % Matlab does not allow 0 as an index, so we start with T(1). ii=T; l=2; TT=5; while T(ii)<=TT u=rand; ii=ii+1; T(ii)=T(ii1)  (1/lambda)*log(u); end plot(T, '.')
The following plot is using TT = 50.
The number of points generated every time on average should be [math]\lambda[/math] * TT.
Markov chain
=)
