Artificial Intelligence for Smarter & Faster Research

What is the scientific achievement?

A collaborative team of DOE scientists developed a new artificial intelligence method for autonomous experimentation.  Their versatile algorithm was integrated into an X-ray scattering instrument and deployed to study nanomaterials without need for human interaction.

Why does this achievement matter?

Machine-guided scientific studies can liberate human scientists from micro-managing experiment details, allowing them to focus instead on understanding the scientific meaning of the results. The methods in this work demonstrate the ability of autonomous methods to achieve high-fidelity searches of experimental problems more efficiently than traditional approaches.

What are the details?

Modern scientific experiments are increasingly complex, requiring scientists to explore innumerable different conditions in their pursuit of next-generation materials. Scientists at Brookhaven National Laboratory and Lawrence Berkeley National Laboratory have developed new artificial intelligence (AI) methods to enable “autonomous experimentation.” In autonomous experiments, the instrument runs without human intervention, automatically collecting data and deciding what measurement to do next. Rather than the human scientist repeatedly deciding what to do next (and then doing it), this autonomous mode automates the process, with the instrument selecting the highest-value experiment to perform. This liberates the human scientist to focus on high-level scientific understanding.

This collaboration demonstrated the effectiveness of a new algorithm for autonomous decision-making. This algorithm selects what measurement to perform by calculating uncertainty, and thus the expected knowledge gain for possible future measurements. In other words, it estimates “what follow-up experiment will teach us the most about this scientific problem” and then automatically launches that experiment. This AI algorithm runs iteratively, collecting data in a highly efficient manner, and thereby automatically reconstructing a useful map of the parameter space being explored.

In addition to developing this general and flexible algorithm, the team deployed the method at an x-ray scattering beamline at Brookhaven National Laboratory. The Complex Materials Scattering (CMS) beamline is operated in partnership between the National Synchrotron Light Source II (NSLS-II) and the Center for Functional Nanomaterials (CFN). The CMS beamline was used to implement this methodology, where the autonomous algorithm selected the sequence of measurements to perform on real material science samples.

CFN Capabilities

The CMS beamline, operated in partnership between NSLS-II and CFN, was used for X-ray scattering experiments.

Publication Reference

M.N. Noack, K.G. Yager, M. Fukuto, G.S. Doerk, R. Li, J.A. Sethian A Kriging-Based Approach to Autonomous Experimentation with Applications to X-Ray Scattering, Scientific Reports 9, 11809 (2019).

https://doi.org/10.1038/s41598-019-48114-3

https://www.nature.com/articles/s41598-019-48114-3.pdf

DOI: 10.1038/s41598-019-48114-3

https://www.osti.gov/pages/biblio/1558244-kriging-based-approach-autonomous-experimentation-applications-ray-scattering

Press Release

Smarter experiments for faster materials discovery (2019, August 28) retrieved 9 September 2019 from https://www.bnl.gov/newsroom/news.php?a=116726

Acknowledgement of Support

The work was partially funded through the Center for Advanced Mathematics for Energy Research Applications (CAMERA), which is jointly funded by the Advanced Scientific Computing Research (ASCR) and Basic Energy Sciences (BES) within the Department of Energy’s Office of Science, under Contract No. DE-AC02-05CH11231. This work was conducted in part at Lawrence Berkeley National Laboratory and Brookhaven National Laboratory. This research used resources of the Center for Functional Nanomaterials and the National Synchrotron Light Source II, which are U.S. DOE Office of Science Facilities, at Brookhaven National Laboratory under Contract No. DE-SC0012704.
